9
Before Using
Part Names
2
Part Names
Entrance Station IXG-DM7, Entrance Station (HID-compatible) IXG-DM7-HID
No. Name & description
1 Speaker
2 Camera
3 LED for night illumination
When a call is placed, the LED will illuminate in low light situations, and will turn off when communication ends.
The light will also turn ON when being monitored by a Tenant Station, Intercom App, Master Station, or Guard
Station.
LED may not turn on depending on the settings.
4 Card reader indicator (Red/Green) (IXG-DM7-HID only)
The light is normally ON (red). If the proximity key is authenticated, it will turn ON (green) for approximately 3
seconds.
5 Microphone
6 Motion Sensor
Detects the motion of visitors and displays the screen. The screen does not display depending on the settings.
7 Card reader (IXG-DM7-HID only)
Allows the door release at the entrance to be unlocked when a card is passed over the card reader.
8 Touchscreen LCD
1
2
3
4
5
6
7
8
