9
Association Settings
Station Settings List and Station List
From the top menu, select Connection and click Association Settings. Here, stations created in the previous
steps will be associated to stations found on the network. Select a station from the Station Settings List and one
from the Station List below. Conrm that the IP address and subnet mask listed in the Station Settings List are
correct, then click
Apply
. This will assign the Station Name and IP Address to the station and reboot the station.
A station reboot usually takes several minutes.
If a Station Search fails immediately, go to File from the top menu and select IXG Support Tool Settings. Find
the Select NIC drop-down and select the correct NIC that Support Tool should use, then click
OK
. Return to
Association Settings to try again. If the Station Search continues to fail immediately, a local antivirus or rewall
may be preventing this action. Disabling one or both of these may be a simple solution in quickly nishing the
initial system conguration.
Scroll down to conrm the stations were successfully associated. The IP and MAC addresses of the stations
will be listed. If the wrong station information was associated to a station, select that station on this list and click
Remove Association
. Once removed, scroll up and associate the correct station.
Associated Station List
Typically, stations deployed across a
managed network cannot be found
by Support Tool unless the network
is congured to allow this broadcast
search. In this case, it may be easier
to move the stations to a switch
local to the programming PC than it
would be to congure the network
to allow a network-wide broadcast.
