7
GB
PART N° UNIT Q.TY NOTE PART DESCRIPTION
01 1 NA for PT045 OCTI-CAM (Stop arrangement)
02 2 NA for PT045 STOP CAP SCREW
03 2 NA for PT045 WASHER
04 2 NA for PT045 NUT (Stop screw)
05* 2 BEARING (Piston back)
06* 1 BEARING (Pinion top)
07* 1 BEARING (Pinion bottom)
08* 2 1 Pcs. for model PT045 THRUST BEARING (Pinion)
09* 2 NA for PT800 PLUG
09.1* 2 O-RING (For PT800)
10 1 THRUST WASHER (Pinion)
11* 2 NA for PT045 “O” RING (Stop screw)
12 2 NA for PT045 and rotation > 90° PISTON GUIDE
13 8/12/16 (A) CAP SCREW (End cap)
14* 2 “O” RING (End cap)
15* 2 BEARING (Piston head)
16* 2 “O” RING (Piston)
1 min. 5/max.12 for PT100 ÷ PT800 SPRING (Cartridge)
17.1
max. 2
for PT045
max. 4
for PT050 N
NA for PT100 ÷ PT800 SPRING (For PT045 ÷ PT050 N)
17.2 NA for PT100 ÷ PT800 SPRING (For PT045 ÷ PT050 N)
17.3 NA for PT100 ÷ PT800 SPRING (For PT045 ÷ PT050 N)
18 1 SPRING CLIP (Pinion)
19 2 NA for PT045 POSITION INDICATOR
20* 1 “O” RING (Pinion bottom)
21* 1 “O” RING (Pinion top)
30 2 END CAP
39 1 for PT045 ÷ PT300 CAP SCREW (Indicator)
39.1 1 for PT350 ÷ PT800 CAP SCREW (Indicator)
39.2 1 for PT350 ÷ PT800 WASHER (Indicator)
40 2 PISTON
41 1 ACTUATOR IDENTIFICATION LABEL
42 2 END CAP LABEL
43
1
SPIGOT (Only on request)
50 1 BODY
60 1 INTEGRAL DRIVE SHAFT
IMAT PT- E
* Suggested SPARE PARTS for maintenance
Notes:
(A) 12 Pcs. for models PT700 / PT750. 16 Pcs. for models PT800
