Page #3 background imageLoading...
Page #3 background image
Customer : CSN
Type : A318/A319/A320/A321
Rev. Date : May 01, 2018
Manual : AMM
Selected applicability : 0054-0054
29-32-12 PB 401 CONF 00 - PRESSURE
SWITCH - SYSTEM - REMOVAL/INSTALLATION
Print Date: July 05, 2018 Page 3 of 19
© AIRBUS S.A.S. ALL RIGHTS RESERVED. CONFIDENTIAL AND PROPRIETARY DOCUMENT.
3. Job Set-up
Subtask 29-32-12-010-050-A
A. Open one main door of the main gear (Ref. AMM TASK 32-12-00-010-001) .
Subtask 29-32-12-865-050-A
B. Open, safety and tag this(these) circuit breaker(s):
PANEL DESIGNATION FIN LOCATION
49VU FLIGHT CONTROLS/ELAC1/NORM/
SPLY
15CE1 B11
105VU FLIGHT CONTROLS/ELAC2/STBY SPLY 16CE2 A02
105VU FLT CTL/ELAC1/STBY SPLY 16CE1 A01
121VU FLIGHT CONTROLS/SEC3/SPLY 21CE3 Q19
121VU FLIGHT CONTROLS/SEC2/SPLY 21CE2 Q18
121VU FLIGHT CONTROLS/ELAC2/NORM/
SPLY
15CE2 R20
Subtask 29-32-12-860-050-A
C. Aircraft Maintenance Configuration
WARNING: OBEY THE HYDRAULIC SAFETY PROCEDURES.
(1) Obey the hydraulic safety procedures (Ref. AMM TASK 29-00-00-910-002) .
(2) Make sure that the Green hydraulic system is depressurized and put it in the maintenance
configuration.
(Ref. AMM TASK 29-00-00-864-001) .
(3) Depressurize the reservoir of the Green hydraulic system (Ref. AMM TASK 29-14-00-614-001) .
(4) Put the WARNING NOTICE(S) in position to tell persons not to pressurize the Green hydraulic
system:
· in the cockpit on the hydraulic section 40VU of the overhead panel,
· on the ground service panel of the Green hydraulic system.
(5) Put the ACCESS PLATFORM 3M (10 FT)- ADJUSTABLE in position at the main door of the main
gear.
(6) Disconnect the isolation coupling of the Power Transfer Unit (PTU) (Ref. AMM TASK 29-23-00-860-
001) .
(7) Put the CONTAINER - HYDRAULIC FLUID RESISTANT in position below the system pressure
switch to collect any hydraulic fluid.
4. Procedure
(Ref. Fig. System Pressure Switch of the Green and Yellow Hydraulic Systems SHEET 1)
Subtask 29-32-12-020-050-A
A. Removal of the System Pressure Switch
(1) Disconnect the electrical connector (1).
(2) Put the CAP - BLANKING on the disconnected electrical connector (1).
(3) Remove the nut (5), the washer (6), the screw (8), the bonding jumper (7) and the clamp (9) from the
system pressure switch (2).
(4) Cut and remove the lockwire.
