| VF, DHT, AES Series Manual
Refrigerated Air Dryer User Manual
56
ITEM# AIRECLPART# QTY DESCRIPTION
1 AG3934265 1 BACKPLATEFITS16x16ENCLOSURE
2 AG3939621 1 COMMUNICATIONMODULE
3 AG3480020 1 ML‐1100PLC
4 AG3933345 11 TERMINALBLOCK,GRAY,J3
5 AG3933672 3 TERMINALBLOCK,BLUE,J3
6 AG3253101 4 TERMINALBLOCK,GREEN/YELLOW,J3
7 AG3251901 6 ENDANCHOR
8 AG3480612 3 TE RMINALBLOCK,GRAY,J10
9 AG3480613 1 TE RMINALBLOCK,GREEN/YELLOW,J10
10 AG3934654 1 POWERSUPPLY,24VDC,30WATTS
11 AG3948855 1 RELAY,DPDT
12 1C932208‐US 1 PLCCABLE
13
AG3254701
1 TRANSFORMER,150VA
B.4 AES Series - Water-Cooled Models 600 - 2,000 scfm; 3 Phase, 460 Volt, 60 Hz
