Table 18.1 – Technical Data – Condensers for Heat Pump Units
Cassette Unit
CSH 18 CSH 24 CSH 30 CSH 36 CSH 42
Units
Condenser Model
YHJD18 YHJD24 YHJD30 YHJD36 YHJD42
Performance
Nominal System Cooling Capacity BTU/h 18,000 24,000 30,000 36,000 42,000
Nominal System SEER 13 13 13 13 13
Construction
Material: Chassis Pre-Treated Galvanized Painted Steel
Color Champagne
Dimensions/Weights
Height (includes Fan Guard) in 28 32 36 40 40
Width in 34 34 34 34 34
Depth in 34 34 34 34 34
Weight lb 172 184 196 208 208
Compressor
Type
Scroll Recip Recip Recip Scroll
Crankcase Heater Fitted
No Yes Yes Yes
No
Condenser
Coil Construction
Round Tube
Plate Fin
Round Tube
Plate Fin
Round Tube
Plate Fin
Round Tube
Plate Fin
Round Tube
Plate Fin
Connections (1)
Suction in 3/4 3/4 3/4 3/4 7/8
Liquid in
3/8 3/8 3/8 3/8
3/8
Refrigerant Charge
Condenser-factory charge lbs-oz 6 - 6 8 - 13 9 - 0 9 - 7 9 - 12
Charge Required-Per Foot of
Pipework oz 0.62 0.62 0.62 0.62
0.67
(1) Refrigerant line sizes should always match condensing unit connection sizes.
