20
The SLIMLINE PERFORMER Ceilin
g
Cassette
–
Ductless Mini-S
p
lit
Technical Manual : AIR 8-105.5
Ceiling Cassette
Table 20.1 – Electrical Data – Condensers for Heat Pump Units
Cassette Unit
CSH 18 CSH 24 CSH 30 CSH 36 CSH 42
Units
Condenser Model
YHJD18 YHJD24 YHJD30 YHJD36 YHJD42
Standard Data
Power Supply 208-230V/1Ph/60Hz
MCA A 11.9 11.2 14.1 19.7 28.6
Maximum Overcurrent Device Amps (1) A 20 15 20 30 50
Minimum Overcurrent Device Amps (2) A 15 15 15 20 30
Compressor
Rated Load Amps (RLA) A 9.0 8.3 10.6 14.7 21.8
Locked Rotor Amps (LRA) A 48 43 54 74 105
Condenser Fan
Rated Load Amps (RLA) A 0.7 0.8 0.8 1.5 1.5
Rated Horsepower hp 1/10 1/8 1/8 1/4 1/4
(1) Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
(2) Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
Table 20.2 – Sound Data – Ceiling Cassette Units
MERCER TABLE
Models
Fan
Speed
SPL,
dBA (1)
Sound Pressure Frequency Spectrum, dB (1)
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz
High 29 37 37 33 29 21 14 10
CCW2/8 Med 26 34 34 30 24 15 12 10
Low 22 31 29 25 17 8 10 8
High 35 42 41 38 35 28 21 12
CCW2/12 Med 32 38 39 36 32 24 16 10
Low 29 37 37 33 29 21 14 10
CSD/CSH 18 High 43 41 45 38 40 33 25 17
CCW 18 Med 39 39 41 35 36 27 19 16
Low 38 38 40 34 34 25 18 16
CSD/CSH 24 High 46 43 47 40 43 37 29 19
CCW 20 Med 43 41 45 38 40 33 25 17
Low 39 39 41 35 36 27 19 16
CSD/CSH 30 High 48 51 49 46 42 34 22 19
CCW 33 Med 44 50 46 43 38 28 18 17
Low 42 49 44 41 36 25 17 16
CSD/CSH 36 High 52 54 54 50 46 41 27 24
CSD/CSH 42 Med 48 51 49 46 42 34 22 19
CCW 36 Low 45 50 47 44 39 31 19 18
(1) SPL is the overall Sound Pressure Level measured at a distance of 5 ft below the fascia in free field, dry coil conditions, referenced to 2 x
10
5
Pa
