Table 17.1 – Technical Data – Condensers for DX Cooling Only Units
Cassette Unit
CSD 18 CSD 24 CSD 30 CSD 36 CSD 42
Units
Condenser Model
YCJD18 YCJD24 YCJD30 YCJD36 YCJD42
Performance
Nominal System Cooling Capacity BTU/h 18,000 24,000 30,000 36,000 42,000
Nominal System SEER 13 13 13 13 13
Construction
Material: Chassis Pre-Treated Galvanized Painted Steel
Color Champagne
Dimensions/Weights
Height (includes Fan Guard) in 28 28 28 28 30
Width in 23½ 23½ 23½ 29 29
Depth in 23½ 23½ 23½ 29 29
Weight lb 97 129 131 145 173
Compressor
Type
Rotary Recip Recip Recip Recip
Crankcase Heater Fitted No No No No No
Condenser
Coil Construction
Plate Fin
Microchannel
Plate Fin
Microchannel
Plate Fin
Microchannel
Plate Fin
Microchannel
Plate Fin
Microchannel
Connections (1)
Suction in
5/8 3/4 3/4 3/4 7/8
Liquid in
3/8 3/8 3/8 3/8
3/8
Refrigerant Charge
Condenser-factory charge lbs-oz 3 - 3 3 - 13 3 - 14 4 - 9 4 - 5
Charge Per Foot of Pipework oz 0.58 0.62 0.62 0.62 0.67
(1) Refrigerant line sizes should always match condensing unit connection sizes.
