Ceiling Cassette
The SLIMLINE PERFORMER Ceilin
Cassette
Ductless Mini-S
lit
7
Technical Manual : AIR 8-105.
Table 7.1 – Performance – DX Cooling Only Units
Model
Cooling
BTU/h SEER
CSD 18
21500 13
CSD 24
25400 13
CSD 30
34800 13
CSD 36
41800 13
CSD 42
45500 13
Table 7.2 – Performance – Heat Pump Units
Model
Cooling
BTU/h
Heating
BTU/h SEER HSPF
CSH 18
21500 16400 13 7.7
CSH 24
25400 21400 13 7.7
CSH 30
34800 27400 13 7.7
CSH 36
41800 32400 13 7.7
CSH 42
45500 37000 13 7.7
Notes:
Test conditions based on ARI210/240.
1. Cooling capacities are based on 80/67°F DB/WB Indoor and 82/65ºF DB/WB Outdoor ambient.
2. Heating capacities are based on 70/60°F DB/WB Indoor and 47/43°F DB/WB Outdoor ambient.
3. All duties based on high fan speed except where stated otherwise.
Table 7.3 – Cooling Performance – Chilled Water Units
Entering
Air
DB ºF @
50% RH
Chilled Water Inlet/Outlet ºF
40/50ºF 45/55ºF
TC SC Flow Pr Drop TC SC Flow Pr Drop
Model BTU/h BTU/h gpm PSI BTU/h BTU/h gpm PSI
72 5,236 5,156 1.1 2.4 3,999 3,999 0.8 1.5
CCW2/8 75 6,528 5,989 1.3 3.5 4,729 4,729 1.0 2.0
80 10,037 7,529 2.0 7.6 7,026 6,107 1.4 4.0
72 8,723 7,261 1.8 1.9 5,623 5,623 1.1 0.9
CCW2/12 75 10,831 8,173 2.2 2.7 7,502 6,604 1.5 1.4
80 14,435 9,644 2.9 4.6 11,236 8,200 2.3 2.9
72 13,728 12,126 2.8 1.9 9,295 9,295 1.9 0.9
CCW 18 75 17,478 13,840 3.5 2.8 11,447 10,853 2.3 1.4
80 24,588 16,659 4.9 5.1 18,432 13,900 3.7 3.1
72 14,810 13,098 3.0 2.1 10,103 10,103 2.0 1.1
CCW 20 75 18,956 14,985 3.8 3.3 12,341 11,716 2.5 1.5
80 26,569 18,022 5.3 5.9 19,971 15,041 4.0 3.6
72
23,570 20,321 4.7
3.5
15,695 15,695 3.2
1.7
CCW 33 75 29,100 22,928 5.8 5.1 19,912 18,365 4.0 2.7
80 41,598 28,029 8.3 9.6 30,595 23,129 6.1 5.6
72 27,054 23,385 5.4 4.5 18,066 18,066 3.6 2.2
CCW 36 75 33,895 26,690 6.8 6.7 22,721 21,074 4.6 3.3
80 47,991 32,334 9.6 12.5 35,934 26,916 7.2 7.5
1. TC = Total Cooling Capacity
2. SC = Sensible Cooling Capacity
3. All duties based on high fan speed.
4. Pressure drops are coil only, excluding valves.
