The SLIMLINE PERFORMER Ceilin
g
Cassette
–
Ductless Mini-S
p
lit
Technical Manual : AIR 8-105.5
Ceiling Cassette
Table 6.1 – Cooling Performance – DX Cooling Only and Heat Pump Units
Entering Air
DB ºF @
50% RH
Fan Speed
High Medium Low
TC SC TC SC TC SC
Model BTU/h BTU/h BTU/h BTU/h BTU/h BTU/h
72 16500 14400 16300 13900 15800 13100
CSD/CSH 18 75 17500 14900 17200 14400 16800 13500
80 19200 15600 18900 15100 18500 14200
72 20000 16800 19600 16100 19300 15600
CSD/CSH 24 75 21000 17300 20600 16500 20400 16000
80 23000 18000 22600 17200 22200 16700
72 27600 25000 27000 23600 26400 22200
CSD/CSH 30 75 29000 25800 27600 25000 27800 22800
80 31400 27000 31000 25400 30200 23800
72 33400 28400 33000 27600 32200 26200
CSD/CSH 36 75 35000 29200 34600 28200 34000 26800
80 38200 30400 37800 29400 37000 27800
72 37800 31600 37200 30200 36800 29400
CSD/CSH 42 75 39500 32400 39000 31000 38500 30000
80 42500 33400 42000 32000 41500 31000
Table 6.2 – Heating Performance – Heat Pump Units
Entering Air
DB ºF
Fan Speed
High Medium Low
Model TC BTU/h TC BTU/h TC BTU/h
50 19100 18900 18600
CSH 18 60 17800 17600 17200
70 16400 16200 16000
50 24400 24000 23800
CSH 24 60 22800 22600 22200
70 21400 21000 20800
50 30400 30200 29800
CSH 30 60 29000 28800 28200
70 27400 27200 26800
50 35800 35600 35000
CSH 36 60 34200 33800 33400
70 32400 32000 31600
50 39500 39000 39000
CSH 42 60 38200 37800 37800
70 37200 36800 36600
Notes:
1. TC = Total Cooling Capacity
2. SC = Sensible Cooling Capacity
3. Cooling capacities are based on 95/75ºF DB/WB Outdoor ambient.
4. Heating capacities are based on 47/43ºF DB/WB Outdoor ambient.
