AIREDALE CSD 18 - Electrical Data

Ceiling Cassette
The SLIMLINE PERFORMER Ceilin
g
Cassette
–
Ductless Mini-S
p
lit
19
Technical Manual : AIR 8-105.
5
Table 19.1 – Electrical Data – Ceiling Cassettes
Units
Model Size
2/8 & 2/12 18, 20, & 24 30, 33, 36, & 42
Chassis Size Small (2 x 2) Medium (3 x 3) Large (3 x 4)
Standard Unit Data
Power Supply 208-230V/1Ph/60Hz 208-230V/1Ph/60Hz 208-230V/1Ph/60Hz
Full Load Amps A 0.65 0.85 1.3
Minimum Circuit Amps (MCA) A 0.74 0.99 1.4
Recommended Fuse A 10 10 10
With Optional Electric Heat (1)
Power Supply 208-230V/1Ph/60Hz 208-230V/1Ph/60Hz 208-230V/1Ph/60Hz
Electric Heat Capacity kW 1.5 3.0 5.0
Full Load Amps A 7.2 13.9 23.1
Minimum Circuit Amps (MCA) A 8.9 19.3 28.8
Recommended Fuse with Heat A 15 20 30
With Optional Booster Xfm
r
(2)
Power Supply 115V/1Ph/60Hz 115V/1Ph/60Hz 115V/1Ph/60Hz
Full Load Amps A 1.3 1.7 2.5
Minimum Circuit Amps (MCA) A 1.5 2.0 2.8
Recommended Fuse A 10 10 10
(1) Standard Unit fitted with optional electric heating elements. Available with 230V model units only.
(2) Standard unit fitted with optional booster transformer for connection to a 115V electrical supply. Electric heat not available in
conjunction with this option.
Table 19.2 – Electrical Data – Condensers for DX Cooling Only Units
Cassette Unit
CSD 18 CSD 24 CSD 30 CSD 36 CSD 42
Units
Condenser Model
YCJD18 YCJD24 YCJD30 YCJD36 YCJD42
Standard Data
Power Supply 208-230V/1Ph/60Hz
MCA A 9.8 12.4 14.7 17.9 21.5
Maximum Overcurrent Device Amps (1) A 15 20 25 30 35
Minimum Overcurrent Device Amps (2) A 15 15 15 20 25
Compressor
Rated Load Amps (RLA) A 7.4 9.3 10.6 13.1 16.0
Locked Rotor Amps (LRA) A 40 43 54 74 84
Condenser Fan
Rated Load Amps (RLA) A 0.5 0.8 1.4 1.5 1.5
Rated Horsepower hp 1/12 1/8 1/4 1/4 1/4
(1) Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
(2) Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
