The SLIMLINE PERFORMER Ceilin
g
Cassette
–
Ductless Mini-S
p
lit
Technical Manual : AIR 8-105.5
Ceiling Cassette
Table 8.1 – Heating Performance – Chilled Water Units with Optional Hot Water Coil
Hot Water 180ºF Inlet / 160ºF Outlet
Entering Air Heating Capacity Flowrate Pressure Drop
Model DB ºF @ 50% RH BTU/h GPM PSI
50 16,819 1.8 3.9
CCW2/8 60 15,292 1.6 3.3
70 13,799 1.4 2.7
CCW2/12 N/A N/A N/A N/A
50 35,763 3.7 3.4
CCW 18 60 32,480 3.4 2.9
70 29,258 3.1 2.4
50 37,938 4.0 3.7
CCW 20 60 34,401 3.6 3.2
70 30,946 3.2 2.7
50 55,683 5.8 4.0
CCW 33 60 51,120 5.3 3.5
70 46,555 4.9 3.0
50 62,005 6.5 4.8
CCW 36 60 56,762 5.9 4.1
70 51,600 5.4 3.5
Table 8.2 – Heating Performance DX Cooling Only and Heat Pump Units with
Optional Hot Water Coil
Hot Water 180ºF Inlet / 160ºF Outlet
Entering Air Heating Capacity Flowrate Pressure Drop
Model DB ºF @ 50% RH BTU/h GPM PSI
50 46,389 4.8 1.3
CSD/CSH 18 60 42,598 4.4 1.1
70 38,746 4.0 0.9
50 50,279 5.3 1.5
CSD/CSH 24 60 46,153 4.8 1.2
70 41,993 4.4 1.0
50 67,912 7.1 3.3
CSD/CSH 30 60 62,277 6.5 2.8
70 56,609 5.9 2.3
50 71,636 7.5 3.6
CSD/CSH 36 60 65,640 6.9 3.1
70 59,600 6.2 2.6
50 77,386 8.1 4.2
CSD/CSH 42 60 70,803 7.4 3.5
70 64,268 6.7 3.0
Notes:
1. All duties based on high fan speed.
2. Pressure drops are coil only, excluding valves.
