Technical Manual : AIR 8-105.
5
Table 9.1 – Heating Performance – Chilled Water Units – Two Pipe Changeover
Hot Water 180ºF Inlet / 160ºF Outlet
Entering Air Heating Capacity Flowrate Pressure Drop
Model DB ºF @ 50% RH BTU/h GPM PSI
50 28,389 3.0 11.0
CCW2/8 60 25,903 2.7 9.4
70 23,605 2.5 8.0
50 33,471 3.5 4.6
CCW2/12 60 30,715 3.2 4.0
70 27,995 2.9 3.4
50 60,388 6.3 5.7
CCW 18 60 55,127 5.8 4.8
70 49,706 5.2 4.0
50 65,350 6.8 6.5
CCW 20 60 59,887 6.3 5.6
70 54,118 5.7 4.7
50 99,476 10.4 10.1
CCW 33 60 91,494 9.6 8.8
70 82,986 8.7 7.4
50 114,225 11.9 13.0
CCW 36 60 105,132 11.0 11.2
70 95,896 10.0 9.5
Notes:
1. All duties based on high fan speed.
2. Pressure drops are coil only, excluding valves.
