Troubleshooting
REFRIGERATION
FAULT
POSSIBLE CAUSE
REMEDY / ACTION
Condenser fan not operating
- power on.
Motor / fan assembly jammed
Isolate unit and check free rotation of motor
/ fan assembly. If faulty - replace.
Fault at motor terminal box supply
terminals
Isolate and check electrical connections
are secure.
Motor internal overheat protector tripped.
&DUU\RXWFRQWLQXLW\FKHFNDWWHUPLQDOV³7.´
in motor terminal box. If tripped and motor
hot - check bearings. If tripped and motor
cold - replace motor.
Power supply failure
Check power supply at circuit breaker.
Wiring to motor
Check voltage at motor terminals.
Faulty motor windings / capacitor
Motor humming would indicate fault in
motor or capacitor.
Minimum speed set too low.
Adjust head pressure controller to suit.
Faulty pressure sensor.
Check electrical connections are secure at
controller and pressure sensor. Replace
controller and sensor (as they are matched
sets).
Faulty Controller.
/LQNZLUHV³OLQH´DQG³ORDG´WRE\SDVV
controller. If motor runs full speed - replace
unit.
Condenser fan runs too fast.
High ambient condition or excessive re-
circulation of air around condenser coil.
Check installation against design.
Minimum speed setting incorrect.
Adjust as necessary.
Incorrect pressure setting.
Adjust sensor screw as necessary.
Faulty Controller.
Replace controller and sensor (as they are
matched sets).
Faulty pressure sensor.
Replace controller and sensor (as they are
matched sets).
Condenser fans runs only
slowly.
Incorrect pressure setting.
Adjust sensor screw as necessary.
Faulty Controller.
Replace controller and sensor (as they are
matched sets).
Faulty Pressure sensor.
Replace controller and sensor (as they are
matched sets).
Motor wired incorrectly.
Check against wiring diagram - correct as
required.
Motor / capacitor faulty.
Replace.
