29 AE: V2016-03
Thermal Fogger AE9 / AE35 Spare Part List
When ordering spare parts, please always mention the pos., part number, descriptions, number of parts
needed.
note: the part without “ # ” is commonly suitable for all appliance types.
the part with “ # ” can only be used on particular mentioned appliance type.
Pos. Part no. Description
1 909-001-000 Solution Tank, HDPE
1/1 909-001-020 Tube Holder
1/2 909-001-010 Tube Holder Cap
2 909-002-000 Tank Cap Assembly (3,4)
3 909-003-000 Tank Cap
7 909-007-000 Cap Assembly (8,9)
8 909-008-000 Cap
9 935-009-000 Gasket
10 909-010-000 Fuel Tank, HDPE
12 935-012-000 Carburettor Cover
13 935-013-000 Gasket, Fiber
15 909-015-000 Gasket
16 935-016-000 Regulating Needle Assembly (17,18)
17 935-017-000 Regulating Needle
18 935-018-000 O-Ring
19# 935-019-000 Atomizer Nozzle Assembly, AE35 (20-22)
19# 909-019-000 Atomizer Nozzle Assembly, AE9 (20-22)
20# 935-020-000
Atomizer Nozzle
AE35
20# 909-020-000 Atomizer Nozzle, AE9
21 935-021-000 O-Ring
22 935-022-000 O-Ring
23/4 909-023-040 Set Screw, M6x5
23/5 909-023-050 Plug
24/3# 935-024-030 Carburettor cpl., AE35
-
-
.,
24/2# 935-024-020 Carburettor Assembly, AE35
24/2# 909-024-020 Carburettor Assembly, AE9
24/1# 935-024-010 Carburettor Housing, AE35
24/1# 909-024-010 Carburettor Housing, AE9
25 935-025-000 Set Screw, M6x20
26# 935-026-000 Swirl Vane, AE35
26# 909-026-000 Swirl Vane, AE9
27# 935-027-000 O-Ring, AE35
27# 909-027-000 O-Ring, AE9
27/1 935-027-010 O-Ring
29 935-029-000 O-Ring
30# 935-030-000
Air Intake Valve Assembly, AE35
32
33
34
34/1
60
61
63
30# 909-030-000
Air Intake Valve Assembly, AE9
(32,33,34,34/1,60,61,63)
