Airofog AE9 - Page 31

30 AE: V2016-03
Pos. Part no. Description
32# 935-032-000 Spacer Plate, AE35
32# 909-032-000 Spacer Plate, AE9
33 935-033-000 Diaphragm
34 935-034-000 Valve Boby
34/1 935-034-010 O-Ring
35
935-035-000
Cap Nut M5
35
935-035-000
Cap Nut
,
M5
36 935-036-000 Fillister Head Screw, M4x12
37 935-037-000 Gasket, Fiber
38/1 935-038-010 Check-Valve Assembly
39 935-039-000 Check-Valve
40 935-040-000 Diaphragm, Viton
41 935-041-000 O-Ring
42 935-042-000 Gasket
43 935-043-000 Connecting Link
44 935-044-000 Gasket, Fiber
46 935-046-000 Air Tube
49 935-049-000 Gasoline Stop Button Assembly (50-52,18,29)
50 935-050-000 Plunger
51 935-051-000 Bushin
g
g
52 935-052-000 Button
54 935-054-000 Gasoline Suction Line Assembly (56,58,59)
56 935-056-000 Screw Fitting
56/1 935-056-010 Gasket
58 935-058-000 Hose with Filter
59 935-059-000 Felt Tube
60
935 060 000
Silencer
60
935
-
060
-
000
Silencer
61
935-061-000 Kunrled Nut
62
935-062-000 Sheet Metal Nut, M5
63 935-063-000 Countersunk Head Screw, M5x20
65 935-065-000 Fillister Head Screw, M5x10
66 935-066-000 Tooth Lock Washer
70 935-070-000 Contact Plate with Cable (71-74)
71 935-071-000 Battery Cover
72 935-072-000 Cable
73 935-073-000 Nut, M5
74 935-074-000 Fillister Head Screw, M5x12
74/1 909-074-010 Plain Washer
76 935-076-000 Fillister Head Screw, M4x30
77
935
-
077
-
000
Cap Nut M4
77
935 077 000
Cap Nut
,
M4
78 935-078-000 Starter Button
79 935-079-000 Ignition Coil
79I 1 935-079-010 Spark Pulg Cable
79I 2 935-079-020 Grommet
80 935-080-000 Grommet
84 909-084-000 Support, Blue
