Airofog AE9 - Page 32

31 AE: V2016-03
Pos. Part no. Description
85 909-085-000 Support, Blue
86 935-086-000 "D" Battery Holder
86/1 935-086-010 "AA" Battery Holder
87 935-087-000 Contact Spring
88 935-088-000 Wing Screw, M5x10
89
909-089-000
Pump Assembly (90 91/1 91)
89
909-089-000
Pump Assembly (90
,
91/1
,
91)
90 909-090-000 Pump Tube
90/1 909-090-010 Check-Valve, Pump Tube
91 909-091-000 Pump Spindle Assembly, 92-96
92 909-092-000 Cap
93 935-093-000 Spring
94 935-094-000 Pump Spindle
95 935-095-000 Collar
96 935-096-000 Handle
97# 935-097-000 Resonator, AE35
97# 909-097-000 Resonator, AE9
98/1 935-098-010 Gasket
98/2 935-098-020 Protection Shield
99 909-099-000 Fixin
g
Device
g
100 909-100-000 Cooling Jacket, Black
102# 935-102-010 Hood, AE35
102# 909-102-010 Hood, AE9
104 935-104-000 Spark Plug Socket
105 935-105-000
Tapping Screw, 2.9x6.5 ISO 07049
106 935-106-000 Hexagon Nut, M6
107
909 107 000
Edge Protection
107
909
-
107
-
000
Edge Protection
108# 935-108-000 Universal Fog Tube, AE35
108# 909-108-000 Universal Fog Tube, AE9
109# 935-109-000 Special Fog Tube for Water Base , AE35
109# 909-109-000 Special Fog Tube for Water Base , AE9
110 909-110-000 Protective Cover
113# 935-113-010 Protective Guard, AE35
113# 909-113-010 Protective Guard, AE9
114 909-114-000 Fog Solution Socket
114/1 909-114-010 Special Fog Solution Socket (Water Base)
116# 935-116-010 Solution Line Teflon, AE35
116# 909-116-010 Solution Line Teflon, AE9
116/1 504-007-007 O-Ring
117/0 8
909
-
117
-
080
Dosage Nozzle 0 8
117/0
.
8
909 117 080
Dosage Nozzle
,
0
.
8
117/1.0 909-117-100 Dosage Nozzle, 1.0
117/1.2 909-117-120 Dosage Nozzle, 1.2
118 909-118-000 Gasket, CF
120 909-120-000 Solution Tap Assembly (22,76x4,121-131)
121 909-121-000 Tap, Lower Part
121/1 909-121-010 Gasket
121/2 909-121-020 Solution Tube
122 935-122-000 Tap, Upper Part
