TABLE OF CONTENTS
1.0 Prefatory note page 16
2.0 Safety instructions page 17
3.0 Placing page 19
3.1 Electric connection page 19
3.2 Air connection page 19
4.0 First use page 20
5.0 Operation page 20
6.0 Maintenance page 21
7.0 Possibilities of failure page 22
8.0 Technical details page 22
ATTENTION
To be able to use this compressor installation properly, a number of mea-
surements must be taken. The following points will contribute to making you a
satisfied user of this installation.
1.0 PREFATORY NOTES
Buying your Airpress compressor installation, you have become the owner of a
compressor installation with a high performance and reliability level. Correct use
and regular maintenance will increase the life of the compressor.
In this manual you will find operation and maintenance instructions. Read it
carefully and keep it as a guide to your compressor.
The compressor has been designed to supply compressed air. In particular the
appliance cannot be used to produce air to be breathed by humans or used on
direct contact with foodstuffs. The appliance must be used only for the purpose for
which it was specifically designed. All other uses are to be considered incorrect
and therefore unreasonable. The manufacturer cannot be held responsible for any
damage resulting from improper, incorrect or unreasonable use. This machine is
not suitable for external installation.
Legend (fig. A)
1 Air filter ( on the back) 8 Pressure gauge for pressure of air
2 Non return valve 9 Plug
3 Safety valve 10 Draintap for condensation water
4 Pressure switch 11 Oil drain plug
5 Reducing valve
6 Quick coupling 13 Oil plug + oil-level indicator
7 Gauge reduced pressure
