AIRPULSE A100 - Box Contents; Speaker Illustration and Controls

Speaker Illustraon
Box Contents
3.5mm to RCA audio cable
5
6
USB
PC
OPT
AUX
Remote control
Acve speaker
Passive speaker
User manual
Speaker connecng cable
Fiber opc input audio cable
RCA audio cable
Power cable
USB connecng cable
Cleaning cloth
1. Volume control/input selecon
Volume control
Rotate clockwise to increase volume; rotate
counter clockwise to reduce volume.
When reaching maximum volume level,
connue to rotate volume control will not
change volume.
Input selecon
Press to switch between PC – AUX – USB –
Opcal – Bluetooth modes.
(As DSP will be reconfigured when input
mode is switched, it is recommended to
press aer the current mode indicator
flashes once.)
Standby control
Press and hold to alternate between Power
on and Stand by mode
2. Bass level adjustment
Room acouscs may dictate which type of
adjustment you need to make to retain the
proper frequency response from the speaker.
Turn from “0” to le to reduce low frequencies;
Turn from “0” to right to increase low
frequencies.
3. Treble level adjustment
Room acouscs may dictate which type of
adjustment you need to make to retain the
proper frequency response from the speaker.
Turn from “0” to le to reduce high frequencies;
Turn from “0” to right to increase high
frequencies.
4. Power switch
Turn on/off speaker power
5. AC input socket
Connect to plug of power cord
6. Auxiliary input port
Connect to audio source devices with
RCA output port using RCA audio cable.
7. PC input port
Connect to PC using 3.5mm to RCA audio
cable, or connect to audio source devices
with RCA output port using RCA audio cable.
8. USB B type port
Connect to audio source devices with
USB output port using USB connecng cable.
9. Opcal input port
Connect to audio source devices with
opcal output port using fiber opc
input audio cable
10. Subwoofer output port
Connect to audio input port of subwoofer
using RCA audio cable
11. Passive speaker connector
Connect to passive speaker using speaker
connecng cable
12. Acve speaker connector
Connect to acve speaker using speaker
connecng cable
13. LED indicator/remote control receiving
window
Indicates current input mode based on
audio sources and input selecon.
English English
