Pos. # Description Qty Pos. # Description Qty Pos. # Description Qty
1 Gear Box Housing 1 63 Inlet flange, Lower housing 1 130 Label, Direction Arrow 1
2 Gear Box Cover (rear) 1 64 O-Ring, Check valve plate 1 131 Name Plate 1
4 Pump Housing Cover 1 (End Plate) 1 65 Check valve plate 1 133 Lable, read manul 1
6 Fan Housing 1 66 Spring, Check valve 1 146 Bushing 1-1/4" x 1" 2
11 Shaft 1 1 67 Check valve guide 1 150 Inlet Filter, IF-130 1
12 Shaft 2 1 70 Flange Adapter, Inlet 1 151 Pipe, extension, Short, inlet 1" 1
13 Gear 1 1 71 Gasket, Flange 1 152 Pipe, extension, inlet 1' 1
14 Gear 2 1 72 Exhaust Silencer assembly (ES type) 1 153 Elbow 1" 1
15 Rotor 1 1 73 Gasket, Silencer assembly (ES type) 1 201 Hex. Socket Head Cap Screw / M16 x 15 8
16 Rotor 2 1 74 Gasket, Silencer 2 203 Hex. Socket Head Cap Screw / M5 x 12 2
17 Spacer 2 75 Spacer, block 1 204 Hex. Socket Head Cap Screw / M8 x 25 1
18 Piston Ring 4 76 Plate (ES Type) 1 206 Hex. Socket Head Cap Screw / M8 x 25 2
19 Sleeve 2 77 Accoustic mat (ES Type) 1 207 Hex. Socket Head Cap Screw / M10 x 100 4
20 O-Ring 2 81 Gasket, Oil Sight Glass 2 209 Washer, Spring Lock, 10mm 4
21 Shaft Seal, 2 83 Oil Sight Glass 2 210 Hex. Socket Head Cap Screw / M8 x 25 1
22 Bearing, 2 85 Pipe, for Drain Pulg 1 211 Hexagon Bolt / M12 x 35 4
23 Bearing cover 1 86 O-ring, Drain Plug 2 212 Washer, Spring Lock, 12mm 4
25 Key, for Gear 2 87 Drain Plug 1 214 Hexagon Bolt (NEMA only) 4
26 Key, for Coupling 1 88 Oil filler Breather, Plastic 1 215 Set Screw / M8 x 10 2
28 Power Lock 4 89 O-Ring for Oil filler 1 216 Set Screw / M8 x 10 2
29 Washer, Spring Lock, 6mm 2 92 Shield Cover, Bottom 1 217 Round Head Bolt / M5 x 12 5
30 Flinger 1 93 Accoustic Mat for Shield Cover, Bottom 1 218 Hex. Socket Head Cap Screw / M10 x 60 6
31 Sleeve 2 94 Shield Cover, Side (VCX) 1 219 Washer, Spring Lock, 10mm 6
32 Bearing, 2 95 Shield Cover, Front (VCX) 1 231 Hex. Socket Head Cap Screw / M8 x 20 4
33 Locking Disk 1 96 Accoustic Mat for Shield Cover, front and Side 1 232 Hex. Socket Head Cap Screw / M6 x 80 4
34 O-Ring 1 97 Foot, Rubber 4 237 Stud / M6 x 70 4
35 Sleeve 1 99 Grill for Fan 2 261 Hex. Socket Head Cap Screw / M10 x 15 4
36 Shaft Seal, 1 100 Coupling, Pump Side 1 262 Hex. Socket Head Cap Screw / M x 2
37 O-Ring, Compressor cover 1 101 Insert, Coupling 1 263 Set Screw / M8 x 20 4
38 O-Ring, Gear Box cover 1 102 Coupling, Motor Side 1 264 Hexagon Nut / M8 4
39 Dowel Pin 4 103 Fan, new, Plastic 1 265 Hex. Socket Head Cap Screw / M10 x 110 2
40 Locking Disk 1 105 Flange Adapter 1 266 Washer, Spring Lock, 10mm 2
47 Locking Disk, side Rotor 2 110 Motor 1 267 Round Head Bolt/ M5 x 10 4
60 Inlet flange, Upper Housing 1 120 Vacuum Regulator 1 291 Round Head Bolt / M5 x 10 11
61 Inlet screen (Conical ) 1 123 Pipe, extension, medium, exhaust 1" 1 292 Washer, Flat, 5mm 11
62 O-Ring, Inlet Flange, low and upper part 2 129 Eye Bolt 1
VCX 60 PART LIST
