1.5 Vacuum Connections
Use a pipe size that is at least the size of the pump outlet connection. Smaller pipe lines result in reduced
pump capacity.
Pumps operating in parallel on a common main line should have a manual or automatic shut-off valve or
positive action check valve installed in the suction line adjacent to the pump suction flange. The built-in
anti-suck back valve should not be used as a shut-off valve for the vacuum system. Remove the plastic
protective cap from the inlet port prior to connection of pump to the system. Should process gas contain
dust or other foreign particles, a suitable in line (inlet) filter should be connected to the inlet port. Contact
Airtech for recommendations.
The following thread sizes are standard on the pumps (NPT thread is available upon request)
Pump Model Inlet Size Exhaust Size
VCX 60 1” 1”
VCX 100 / VCX 100B 1-1/2” 1-1/2”
VCX 150 / VCX 150B / VCX155 1-1/2” 1-1/2”
VCX 250 / VCX 250B / VCX205 2” 2”
VCX 255 / VCX 305 2” 2”
VCX 300 / VCX 300B 2” 2”
VCX 400 & 505 3" 3"
VCX 515 DN80 PN10 3”
