Pos. # Description Qty Pos. # Description Qty Pos. # Description Qty Pos. # Description Qty
1 Gear Box Housing (NEW) 1 37 O-Ring, Compressor cover 2 92 Shield Cover, Bottom with mat 1 207 Hex. Socket Head Cap Screw / M10 x 100 8
2 Gear Box Cover (rear) 1 38 O-Ring, Gear Box cover 1 93 Accoustic Mat for Shield Cover, Bottom 1 207 Hex. Socket Head Cap Screw / M10 x 130 8
3 Pump Housing 1 39 Dowel Pin 8 94 Shield Cover, Side, with mat (NEW GB) 1 209 Washer, Spring Lock, 10mm 1
4 Pump Housing Cover 1 (End Plate) 1 40 Locking Disk 1 95 Shield Cover, Front with mat 1 210 Hex. Socket Head Cap Screw / M8 x 25 1
6 Fan Housing 1 51 Inlet flange, Exhaust Silencer 1 96 Accoustic Mat for Shield Cover, front and Side 1 211 Hexagon Bolt / M12 x 35 4
11 Shaft 1 1 52 Gasket, Exhaust Silencer 1 97 Foot, Rubber 4 212 Washer, Spring Lock, 12mm 4
12 Shaft 2 1 58 Inlet Connection Housing 1 98 Cover, Plastic Foot Mount 4 213 Hexagon Bolt / M12 x 25 4
13 Gear 1 1 59 Exhaust Silencer assembly 1 99 Grill for Fan 2 214 Hexagon Bolt / M12 x 45 2
14 Gear 2 1 60 Inlet flange, Upper Housing 1 100 Coupling, Pump Side 1 215 Set Screw / M8 x 10 2
15 Rotor 1 1 61 Inlet screen (Conical ) 1 101 Insert, Coupling 1 216 Set Screw / M8 x 10 2
16 Rotor 2 1 62 O-Ring, Inlet Flange, low and upper part 2 102 Coupling, Motor Side 1 217 Round Head Bolt / M5 x 12 5
17 Spacer 2 63 Inlet flange, Lower housing 1 103 Fan, new, Plastic 1 218 Hex. Socket Head Cap Screw / M10 x 60 6
18 Piston Ring 4 64 O-Ring, Check valve plate 1 105 Flange Adapter 1 219 Washer, Spring Lock, 10mm 6
19 Sleeve 2 65 Check valve plate 1 110 Motor 1 231 Hex. Socket Head Cap Screw / M8 x 20 4
20 O-Ring 2 66 Spring, Check valve 1 120 Vacuum Regulator 1 232 Hex. Socket Head Cap Screw / M6 x 80 4
21 Shaft Seal, 2 67 Check valve guide 1 122 Silencer, exhaust 1 233 Hex. Socket Head Cap Screw / M6 x 65 4
22 Bearing, 2 69 Gasket, Inlet Connection Housing 1 122.1 Baffle, for Exhaust Silencer 1 241 Hex. Socket Head Cap Screw / M8 x 60 4
23 Bearing cover 2 70 Flange Adapter, Inlet 1 123 Pipe, extension, medium, exhaust 1 242 Washer, Spring Lock, 8 mm 4
24 Key, for Rotor 2 71 Gasket, Flange 2 129 Eye Bolt 1 243 Hex. Socket Head Cap Screw / M6 x 25 6
25 Key, for Gear 1 80 Pipe, for Oil sight glass 2 130 Label, Direction Arrow 1 244 Washer, Spring Lock, 6mm 6
26 Key, for Coupling 1 81 Gasket, Oil Sight Glass 4 131 Name Plate 1 246 Hex. Socket Head Cap Screw / M6 x 60 6
27 Sleeve 2 82 Plate 1 132 Lable, Hot 1 261 Hex. Socket Head Cap Screw / M10 x 15 6
28 Power Lock 1 83 Oil Sight Glass 1 133 Lable, read manul 1 263 Set Screw / M8 x 20 4
29 Washer, Spring Lock, 6mm 2 84 Plug for oil Sight Glass 1 141 Bushing 2" x 1_1/2" 1 264 Hexagon Nut / M8 4
30 Flinger 1 85 Pipe, for Drain Pulg 2 157 Plug 1/8" 1 265 Hex. Socket Head Cap Screw / M10 x 110 2
31 Sleeve 2 86 O-ring, Drain Plug 4 201 Hex. Socket Head Cap Screw / M6 x 15 8 266 Washer, Spring Lock, 10mm 2
32 Bearing, 2 87 Drain Plug 2 202 Hex. Socket Head Cap Screw / M6 x 25 6 267 Round Head Bolt/ M5 x 10 4
33 Locking Disk 3 88 Oil filler Breather, Plastic 1 203 Hex. Socket Head Cap Screw / M4 x 12 2 268 Round Head Bolt / M5 x 10 4
34 O-Ring 1 89 O-Ring for Oil filler 1 204 Hex. Socket Head Cap Screw / M8 x 25 1 291 Round Head Bolt / M5 x 10 12
35 Sleeve 1 90 Foot Mount, Right 1 205 Hex. Socket Head Cap Screw / M5 x 8 2 292 Washer, Flat, 5mm 12
36 Shaft Seal, 1 91 Foot Mount, Left 1 206 Hex. Socket Head Cap Screw / M8 x 25 8
VCX 100/150 PARTS LIST
