AirTech VCX 60 - Page 26

Pos.# Description Qty Pos.# Description Qty Pos.# Description
Qty
1 Gear Box Housing (NEW) 1 62
O-Ring, Inlet Flange, low and upper part
1worrAnoitceriD,lebaL0312
2
Gear Box Cover (rear)
1
63
Inlet flange, Lower housing
1 131 Name Plate 1
3
Pump Housing
1 64
O-Ring, Check valve plate
1
132 Lable, Hot
1
4
Pump Housing Cover 1 (End Plate)
1 65
Check valve plate
1 133
Lable, read manul
1
6
Fan Housing
1 66
Spring, Check valve
1 134 Pipe, extension, medium, 2" 1
11
Shaft 1
1 67
Check valve guide
1 201 Hex. Socket Head Cap Screw / M6 x 15 8
12 Shaft 2 1 68
Inlet Connection Housing
1 202 Hex. Socket Head Cap Screw / M6 x 30 8
13 Gear 1 1
69
Gasket, Inlet Connection Housing
1 203 Hex. Socket Head Cap Screw / M6 x 15 2
14 Gear 2 1
70
Flange Adapter, Inlet
1 204 Hex. Socket Head Cap Screw / M12 x 25
1
15 Rotor 1 1 71
Gasket, Flange
2
205 Hex. Socket Head Cap Screw / M5 x 8
2
16
Rotor 2
1 80
Pipe, for Oil sight glass
2 206 Hex. Socket Head Cap Screw / M12 x 25 2
17 Spacer 2 81
Gasket, Oil Sight Glass
4 207 Hex. Socket Head Cap Screw / M12 x 100 / 120 8
18
Piston Ring
4
82 Plate 1
209
Washer, Spring Lock, 12mm
8
19
Sleeve 2
83
Oil Sight Glass
1 210 Hex. Socket Head Cap Screw / M12 x 25 1
20
O-Ring
2
84
Plug for oil Sight Glass
1 211
Hexagon Bolt / M12 x 35
4
21 Shaft Seal
2
85
Pipe, for Drain Plug
2
212
Washer, Spring Lock, 12mm
4
22
Bearing,
2 86
O-ring, Drain Plug
4 213
Hexagon Bolt / M12 x 25
4
23
Bearing cover
2 87
Drain Plug
2 214
Hexagon Bolt / (NEMA only)
4
24
Key, for Rotor
2 88 Oil filler Breather, Plastic 1 215 Set Screw / M8 x 15 2
25
Key, for Gear
1
89
O-Ring for Oil filler, for PN 100.088.01
1 216 Set Screw / M8 x 15
2
26
Key, for Coupling
1
90
Foot Mount, Right
1 217 Round Head Bolt / M5 x 10
5
27
Sleeve 2 91 Foot Mount, Left
1 218 Hex. Socket Head Cap Screw / M12 x 60
6
28 Power Lock 1 92 Shield Cover, Bottom 1
219
Washer, Spring Lock, 12mm
6
29
Washer, Spring Lock, 6mm
2 93 Accoustic Mat for Shield Cover, Bottom 1 231 Hex. Socket Head Cap Screw / M12 x 25 4
30
Flinger
1 94
Shield Cover, Side, (NEW GB)
1 232 Hex. Socket Head Cap Screw / M6 x 120
4
31 Sleeve
2
95 Shield Cover, Front 1 233 Hex. Socket Head Cap Screw / M8 x 115
4
32
Bearing,
2
96
Accoustic Mat for Shield Cover, Front & Side
1 241 Hex. Socket Head Cap Screw / M12 x 20
4
33
Locking Disk
3 97 Foot, Rubber 4 243 Stud / M8 x 40 4
34
O-Ring
1 98 Cover, Plastic Foot Mount 4 244 Nut / M8 4
35 Sleeve 1 99 Grill for Fan 2 261 Hex. Socket Head Cap Screw / M12 x 25 6
36 Shaft Seal, 1 100
Coupling, Pump Side
1 263 Set Screw / M10 x 20 4
37
O-Ring, Compressor cover,
2 101
Insert, Coupling
1 264
Hexagon Nut / M10
4
38
O-Ring, Gear Box cover,
1 102
Coupling, Motor Side
1 265
Hex. Socket Head Cap Screw / M12 x 140
2
39
Dowel Pin 8 103 Fan, new, Plastic
1 266
Washer, Spring Lock, 12mm
2
40
Locking Disk
1 105
Flange Adapter
1 267 Round Head Bolt/ M5 x 10
4
51
flange, Exhaust Silencer
1 110 Motor 1
268 Round Head Bolt / M5 x 10
4
52 Gasket, Exhaust Silencer 1 120
Vacuum Regulator
1 291 Round Head Bolt / M5 x 10 12
te
l
nI,recn
e
li
S1
211ylbmessarecneliS95 21mm5,talF,rehsaW29
2
1
60
Inlet flange, Upper Housing, G 2"
1 123 Pipe, extension, medium, 1_1/2"
1
61
Inlet screen (Conical )
1 129 Eye Bolt
1
VCX 250B / 300B PART LIST
