AirTech VCX 60 - Page 28

POS# Description Q'ty POS# Description Q'ty POS# Description Q'ty
1 Gear Box Housing
1
40 Locking Disk
1
105 Flange Adapter (IEC 112M, NEMA 213TC, 215TC)
1
2 Gear Box Cover (rear)
1
47 Locking Disk, side Rotor
2
110 Motor
1
4 Pump Housing Cover 1 (End Plate)
1
52 Gasket, Exhaust Silencer, Steel Silencer
1
120 Vacuum Regulator
1
6 Fan Housing
1
59 Silencer assembly steel
1
130 Label, Direction Arrow
1
10 Sleeve
2
60
Inlet flange, Upper Housing, G 2"
1
131 Name Plate
1
11 Shaft 1
1
61
Inlet screen (Conical )
1
158 Base
1
12 Shaft 2
1
62
O-Ring, Inlet Flange, upper part
1
159 Cover, Exhaust
1
13 Gear 1
2
64
O-Ring, Check valve plate
1
160 Seal
1
15 Rotor 1
1
65
Check valve plate
1
571 Washer, Spring Lock, 6mm
8
16 Rotor 2
1
66
Spring, Check valve
1
573 Washer, Spring Lock, 10mm
11
17 Spacer
2
67
Check valve guide
1
574 Washer, Spring Lock, 12mm
22
18 Piston Ring
4
76 Plate (vertical)
1
577 Hexagon Nut M10
11
19 Sleeve
2
77 Accoustic mat
1
641 Hex. Socket Head Cap Screw / M5 x 15
5
20 O-Ring
2
78 Plate (horizontal)
1
643 Hex. Socket Head Cap Screw / M6 x 10
4
21 Shaft Seal,
2
79 Support isolator
14
644 Hex. Socket Head Cap Screw / M6 x 15
12
22 Bearing,
2
81 Gasket, Oil Sight Glass
1
650 Hex. Socket Head Cap Screw / M6 x 65
4
23 Bearing cover (Plate)
1
83 Oil Sight Glass
1
656 Hex. Socket Head Cap Screw / M12 x 25
2
24 Bearing cover
1
85 Pipe, for Drain Pulg
1
670 Hex. Socket Head Cap Screw / M12 x 50
14
25 Key, for Gear
2
86 O-ring, Drain Plug
2
673 Hex. Socket Head Cap Screw / M12 x 110
4
26 Key, for Coupling
1
87 Drain Plug
1
678 Hex. Socket Head Cap Screw / M12 x 25
2
27 Sleeve
2
88 Oil filler Breather, Plastic
1
695 Hexagon Bolt / M12 x 25 (IEC 112M, NEMA 213TC, 215TC)
4
28 Power Lock (VCX-305)
2 (4)
89 O-Ring for Oil filler
1
696 Hexagon Bolt (NEMA only)
4
30 Flinger
2
92 Shield Cover, Bottom
1
697 Hexagon Bolt / M12 x 35
4
31 Sleeve
2
93 Accoustic Mat for Shield Cover, Bottom
1
707 Set Screw / M8 x 15
2
32 Bearing,
2
94 Shield Cover, Side
1
709 Set Screw / M8 x 10
2
33 Locking Disk
1
95 Shield Cover, Front
1
710 Set Screw / M10 x 15
3
34 O-Ring
1
96 Accoustic Mat for Shield Cover, front and Side
1
711 Set Screw / M10 x 20
4
35 Sleeve
1
97 Foot, Rubber
7
712 Set Screw / M10 x 25
3
36 Shaft Seal,
1
100 Coupling, Pump Side
1
713 Set Screw / M10 x 35
4
37 O-Ring, Compressor cover,
1
101 Insert, Coupling
1
716 Eye Bolt M12
1
38 O-Ring, Gear Box cover,
1
102 Coupling, Motor Side
1
724 Botton Flange Bolt M5x8
44
39 Dowel Pin
4
103 Fan, new, Plastic
1
VCX 255 PARTS LIST
