Pos. # Description Qty Pos. # Description Qty Pos. # Description Qty Pos. # Description Qty
1 Gear Box Housing (NEW) 1 38 O-Ring, Gear Box cover, 1 96 Accoustic Mat for Shield Cover, Front & Side 1 212 Washer, Spring Lock, 12mm 4
2 Gear Box Cover (rear) 1 39 Dowel Pin 12 97 Foot, Rubber 4 213 Hexagon Bolt / M12 x 25 4
3 Pump Housing 1 40 Locking Disk 1 98 Cover, Plastic Foot Mount 4 215 Set Screw / M8 x 15 2
4 Pump Housing Cover 1 (End Plate) 1 41 O-ring, Bearing cover 2 99 Grill for Fan 2 216 Set Screw / M8 x 15 2
5 Pump Housing Cover 2 (End Plate) 1 42 Cover, Bearing 2 100 Coupling, Pump Side 1 217 Round Head Bolt / M5 x 12 5
6 Fan Housing 1 43 Nipple set, grease 2 101 Insert, Coupling 1 218 Hex. Socket Head Cap Screw / M10 x 60 6
7 Pump Housing Cover (front) 1 44 O-Ring 2 102 Coupling, Motor Side 1 219 Washer, Spring Lock, 10mm 6
11 Shaft 1 1 51 Exhaust Silencer, Inlet Flange 1 103 Fan, new, Plastic 1 231 Hex. Socket Head Cap Screw / M12 x 25 4
12 Shaft 2 1 52 Gasket, Exhaust Silencer 1 105 Flange Adapter 1 232 Hex. Socket Head Cap Screw / M8 x 160 4
13 Gear 1 1 53 Exhaust Silencer, Outlet Flange (Threaded) 1 110 Motor 1 233 Hex. Socket Head Cap Screw / M8 x 20 4
14 Gear 2 1 54 Gasket, ES Outlet Flange 1 115 Base W/Bolt, Nut for Motor 1 241 Hex. Socket Head Cap Screw / M12 x 70 4
15 Rotor 1 1 59 Exhaust Silencer assembly 1 120 Vacuum Regulator 1 242 Washer, Spring Lock, 12mm 4
16 Rotor 2 1 60
Inlet flange, Upper Housing (Threaded), G 3"
1 121 Silencer, Inlet 1 243 Hex. Socket Head Cap Screw / M8 x 30 6
17 Spacer 2 61
Inlet screen (Conical )
1 123 Pipe, extension, medium, Inlet, 1_1/2" 1 244 Washer, Spring Lock, 8mm 6
18 Piston Ring 8 68 Inlet Connection Housing 1 128 Pipe, extension, shor, Inlet, 1_1/2" 1 245 Hex. Socket Head Cap Screw / M8 x 120 4
19 Sleeve 4 69 Gasket, Connection Housing 2 129 Eye Bolt 1 246 Hex. Socket Head Cap Screw / M8 x 90 11
20 O-Ring 4 70 Flange Adapter, Inlet 1 130 Label, Direction Arrow 1 247 Hex. Socket Head Cap Screw / M6 x 20 6
21 Shaft Seal 4 71 Gasket, Flange 2 131 Name Plate 1 261 Hex. Socket Head Cap Screw / M12 x 25 6
22 Bearing, 2 80 Pipe, for Oil sight glass 2 132 Lable, Hot 1 263 Set Screw / M12 x 30 4
23 Bearing cover 2 81 Gasket, Oil Sight Glass 4 133 Lable, read manul 1 264 Hexagon Nut / M12 4
24 Key, for Rotor 2 82 Plate 1 144 Bushing 3" 2 265 Hex. Socket Head Cap Screw / M12 x 140 2
25 Key, for Gear 1 83 Oil Sight Glass 1 156 Elbow 1_1/2" 1 266 Washer, Spring Lock, 12mm 2
26 Key, for Coupling 1 84 Plug for oil Sight Glass 1 157 Plug 1/8" 1 267 Round Head Bolt/ M5 x 10 4
27 Sleeve 2 85 Pipe, for Drain Plug 2 201 Hex. Socket Head Cap Screw / M6 x 15 8 268 Round Head Bolt / M5 x 10 4
28 Power Lock 1 86 Gasket, Drain Plug 2 202 Hex. Socket Head Cap Screw / M6 x 30 8 269 Bolt / M14 x 130 1
29 Wahser, Spring 2 87 Drain Plug 2 203 Hex. Socket Head Cap Screw / M6 x 15 2 270 Hexagon Nut / M14 2
30 Flinger 1 88 Oil filler Breather, Plastic 1 204 Hex. Socket Head Cap Screw / M12 x25 1 291 Round Head Bolt / M5 x 10 12
31 Sleeve, 1 89 O-Ring for Oil filler, for PN 100.088.00 1 205 Hex. Socket Head Cap Screw / M5 x 8 2 292 Washer, Flat, 5mm 12
32 Bearing, 2 90 Foot Mount, Right 1 206 Hex. Socket Head Cap Screw / M12 x25 2
33 Locking Disk 3 91 Foot Mount, Left 1 207 Stud Bolt / M12 x 275 / 290 8
34 O-Ring 1 92 Shield Cover, Bottom, with mat 1 208 Hexagon Nut / M12 8
35 Sleeve, 1 93 Accoustic Mat for Shield Cover, Bottom 1 209 Washer, Spring Lock, 12mm 8
36 Shaft Seal, 1 94 Shield Cover, Side, with mat (NEW GB) 1 210 Hex. Socket Head Cap Screw / M12 x 25 1
37 O-Ring, Compressor cover, 2 95 Shield Cover, Front with mat 1 211 Hexagon Bolt / M12 x 35 4
VCX 400/505 PARTS LIST
