POS# Description Q'ty POS# Description Q'ty POS# Description Q'ty
1 Gear Box Housing
1
47 Locking Disk, Front
2
105 Flange Adapter
1
2 Gear Box Cover (rear)
1
52 Gasket, Exhaust
1
110 Motor
1
4 Pump Housing Cover (End Plate)
1
57 Stud Bolt
4
120 Vacuum Regulator
1
1
59 Silencer assembly steel
1
130 Label, Direction Arrow
1
10 Sleeve
2
60
Inlet Flang
1
131 Name Plate
1
11 Shaft 1
1
61
Inlet screen (Conical )
1
158 Base
1
12 Shaft 2
1
62
O-Ring, Inlet Flange
2
159 Cover, Exhaust
1
13 Gear
2
64
O-Ring, Check valve plate
1
160 Seal
1
15 Rotor 1
1
65
Check valve plate
1
571 Washer, Spring Lock, 6mm
16
16 Rotor 2
1
66
Spring, Check valve
1
573 Washer, Spring Lock, 12mm
17
17 Spacer
2
67
Check valve guide
1
574 Washer, Spring Lock, 10mm
14
18 Piston Ring
4
76 Plate (vertical)
1
577 Hexagon Nut M12
13
2
77 Accoustic mat
1
641 Hex. Socket Head Cap Screw / M5
5
2
78 Plate (horizontal)
1
643 Hex. Socket Head Cap Screw / M5
4
2
79 Support isolator
15
644 Hex. Socket Head Cap Screw / M6
16
2
81 Gasket, Oil Sight Glass
1
650 Hex. Socket Head Cap Screw / M8
3
2
83 Oil Sight Glass
1
652 Washer, Spring Lock, 8mm
3
2
85 Pipe, for Drain Pulg
1
656 Hex. Socket Head Cap Screw / M12
2
1
86 O-ring, Drain Plug
2
670 Hex. Socket Head Cap Screw / M10
14
2
87 Drain Plug
1
673 Hex. Socket Head Cap Screw / M12
4
2(4)
88 Oil filler Breather, Plastic
1
678 Hex. Socket Head Cap Screw / M16
2
2
89 O-Ring for Oil filler
1
695 Hexagon Bolt / M12
4
2
92 Shield Cover, Bottom
1
696 Hexagon Bolt (NEMA only)
4
2
93 Accoustic Mat for Shield Cover, Bottom
1
697 Hexagon Bolt / M12
4
1
94 Shield Cover, Side
1
707 Set Screw / M8
2
1
95 Shield Cover, Front
1
709 Set Screw / M8
2
1
96 Accoustic Mat for Shield Cover, front and Side
1
710 Set Screw / M12
5
1
97 Foot, Rubber
9
711 Set Screw / M12
4
37 O-Ring, Compressor cover,
1
100 Coupling, Pump Side
1
712 Set Screw / M12
5
38 O-Ring, Gear Box cover,
1
101 Insert, Coupling
1
716 Eye Bolt M16
2
4
102 Coupling, Motor Side
1
724 Botton Flange Bolt M5
37
