Airwell AWAU-YBDE024-H11 User Manual (English)

Questions and Answers:

A
Andrew JonesAug 19, 2025
Why is the cooling capacity of my Airwell AWAU-YBDE024-H11 not sufficient?
- G
  greeneloriAug 19, 2025
  If your Airwell Air Conditioner isn't cooling sufficiently, several factors could be the cause: * The unit size may not be adequate for the room's load. Check if a larger unit is needed. * The piping size might not match the system specifications. Verify correct installation, diameter size and total length according to unit specifications. * There may be a refrigerant leak. Check the refrigeration system. * There may be a refrigerant clog. Inspect and repair any clogging, especially near the EEV. * Electronics control problem or protection. Check for any fault code shown on display board and act accordingly. * Compressor failure. Check if fault code # is shown on display board. If so, fix the problem according to 13.5.7 or replace driver.
K
Kyle WarrenAug 21, 2025
What to do if my Airwell AWAU-YBDE024-H11 Air Conditioner indoor unit does not respond to the remote control?
- R
  Robert CookAug 21, 2025
  If your Airwell Air Conditioner indoor unit isn't responding to the remote control, first check the remote control batteries. If that doesn't solve the problem, and if the cause is 'Check continuity of each wire of the display wires/pins with Ohm meter', replace the display box or indoor Electronic Assembly.
D
david60Aug 25, 2025
Why is the heating capacity of my Airwell AWAU-YBDE024-H11 not sufficient?
- B
  brittanycarrollAug 25, 2025
  If your Airwell Air Conditioner isn't heating sufficiently, it could be due to: * Reverse valve. Check reversing valve operation. * Deicing not performed well (during low outdoors temperatures). Check OCT and OAT thermistors fault codes (#1 and 4). Check OCT thermistor if connected well to pipe. Check OAT thermistor if connected well. Check the thermistors operation.
S
Sandra OliverAug 26, 2025
Why is my Airwell Air Conditioner outdoor unit coil freezing in heat mode?
- T
  Timothy CochranAug 26, 2025
  If the outdoor unit coil of your Airwell Air Conditioner is freezing in heat mode and the base is blocked with ice: * It could be due to hard conditions of low temperatures and high humidity. Check that there are no obstructions to the outdoor unit coil air inlet. * Check that all holes in bottom of outdoor unit base are open and clean from dirt. * Check OCT and OAT thermistors. * Connect base heater.
J
Joseph HodgesAug 28, 2025
What to do if there is water leakage from my Airwell AWAU-YBDE024-H11 Air Conditioner indoor unit?
- M
  Madeline CarterAug 28, 2025
  If you notice water leaking from your Airwell Air Conditioner's indoor unit, the most likely cause is a blocked drainage tube. Inspect the drainage tube and clear any blockage to resolve the issue.
T
Teresa DrakeAug 30, 2025
Why does the fuse keep burning in my Airwell Air Conditioner indoor unit controller?
- Z
  Zachary BaileyAug 30, 2025
  If the fuse in your Airwell Air Conditioner's indoor unit controller has burned out, it could be due to a short circuit between wires. Inspect for any cuts or exposed supply wires, or miss-wiring. Another cause could be failure of the indoor unit fan motor, so check the motor and capacitor for any cuts or exposed wires. If the problem persists, replace the fuse.
G
Gregory ThorntonSep 1, 2025
How to troubleshoot an Airwell AWAU-YBDE024-H11 Air Conditioner when the indoor fan won't start?
- J
  Jacob BurkeSep 1, 2025
  If the indoor fan of your Airwell Air Conditioner isn't starting, but the louvers are open and the green LED is on, it could be due to several reasons: * If the unit is in heat mode and the coil isn't warm yet, change to Cool or Fan mode. * There may be a failure of the indoor unit fan motor. Check the motor and capacitor for any cuts or exposed wires. * There could be a problem with the controller or motor capacitor. Change to high speed and check the power supply to the motor is higher than 220VAC. * If still not OK, replace indoor Electronic Assembly.
Y
Yolanda DanielsSep 3, 2025
Why is the display board off on my Airwell AWAU-YBDE024-H11 Air Conditioner outdoor unit?
- T
  Tyler HopkinsSep 3, 2025
  If the display board and LEDs on your Airwell Air Conditioner's outdoor unit are off, it could be due to: * No power supply. Check the supply voltage to main terminals L and N with a voltmeter. * Miss-wiring. Check all supply wiring to the controller and terminals according to the wiring diagram. * Loose connection. Check all power wiring connections. * Burnt fuse. Check the fuse on the main board. * If still not OK, replace main board.
S
Stephen JacksonSep 5, 2025
Why is the power indicator LED off on my Airwell AWAU-YBDE024-H11 indoor unit?
- S
  shieldsallisonSep 5, 2025
  If the red LED power supply indicator on your Airwell Air Conditioner indoor unit isn't lighting up, it could be due to: * No power supply. Check the supply voltage to main terminals L and N with a voltmeter. * Miss-wiring. Check all supply wiring to the controller and terminals according to the wiring diagram. * Loose connection. Check all power wiring connections. * Display and display cable. Check continuity of each wire of the display wires/pins with an Ohm meter. * If still not OK, check if the fuse is burnt.
J
John NortonSep 8, 2025
What to do if the compressor of my Airwell AWAU-YBDE024-H11 Air Conditioner does not start?
- V
  Victor IngramSep 8, 2025
  If the compressor of your Airwell Air Conditioner isn't starting, it could be due to: * One or some components are not operating well. Check for any fault code shown on the display board and act accordingly. * Electronics control problem or protection. * PFC Chock coil. Check the PFC Chock coil. * Driver failure. Check if fault code # is shown on display board. If so, fix the problem according to 13.5.4 or replace driver. * If still not OK, replace compressor.

Airwell AWAU-YBDE024-H11 Specifications

General

Cooling Capacity	2.4 kW
Energy Efficiency Ratio (EER)	3.21
Refrigerant	R32
Power Supply	220-240V, 50Hz
Coefficient of Performance (COP)	3.61
Type	Split System
Heating Capacity	2.5 kW
Outdoor Unit Noise Level	50 dB
Outdoor Unit Weight	23 kg

Summary

Introduction

General Features

Overview of the HJD DCI series, including its expansion and key characteristics.

Indoor Unit Details

Features and specifications of the HJD DCI indoor units, including display and filtration.

Outdoor Unit Details

Features and specifications of the HJD DCI outdoor units, including connections and accessories.

System Specifications

Details on model matching and refrigerant type (R410A) for the HJD DCI series.

Product Data Sheet

Model Specifications

Detailed technical specifications for HJD009, HJD012, HJD018, HJD024, and HJD030 DCI models.

Rating Conditions

Operating Limits

Defines the cooling and heating operating temperature and voltage limits for the R410A system.

Outline Dimensions

Unit Dimensions

Provides dimensional drawings for indoor and outdoor units of the HJD/YBDE series.

Performance Data

Model Performance Specifications

Cooling and heating capacity data, power input, and fan performance for each model.

Capacity Correction Factors

Factors affecting performance based on outdoor temperature and tubing length.

Pressure Curves

Suction and discharge pressure curves versus outdoor temperature for cooling and heating modes.

Sound Level Characteristics

Sound Pressure Level Data

Sound pressure level spectrums and NC curves for indoor and outdoor units.

Electrical Data

Single Phase Unit Electrical Specs

Electrical requirements, current ratings, and wiring specifications for single-phase units.

Wiring Diagrams

HJD Series Wiring Diagrams

Detailed wiring diagrams for indoor and outdoor units of the HJD series.

Tubing Connections

Connection Details and Torque

Guidelines for connecting refrigerant tubing, including flare nut torque and tube bending.

Refrigeration Diagrams

Heat Pump Model Diagram

Schematic diagram illustrating the refrigerant flow for heat pump models.

Electrical Connections

HJD Series Electrical Connections

Diagrams showing how to connect indoor and outdoor units electrically.

Control System

Abbreviations and Overview

Glossary of terms and a block diagram of the control system architecture.

Control Features and Modes

Details on system features, operating modes (Cool, Heat, Auto, Dry, Sleep), and sensor functions.

System Parameters and Settings

Configuration options, jumper settings, DIP switches, and system parameters for operation.

Troubleshooting and Diagnostics

Information on fault codes, system failures, and diagnostic procedures for the control system.

Troubleshooting

Precautions and Warnings

Essential safety precautions for handling electrical components and high voltage.

System Failures and Corrective Actions

Common system problems, probable causes, and corrective actions for indoor and outdoor units.

Component Checking Procedures

Step-by-step guidance for checking key components like motors, sensors, and EEV.

Exploded View & Spare Part List

Indoor Unit Diagrams and Parts

Exploded views and spare part lists for various indoor unit models (HJD series).

Outdoor Unit Diagrams and Parts

Exploded views and spare part lists for various outdoor unit models (YBDE series).
