Airwell AWSI-CFV007-N11 Service Manual

4
Model AWSI-CFV016-N11 AWSI-CFV018-N11 AWSI-CFV024-N11
Power supply V-Ph-Hz 1/220~230/50/60 1/220~230/50/60 1/220~230/50/60
Cooling
Capacity kBtu/h 15.3 19.1 24.2
Capacity kW 4.5 5.6 7.1
Power input W 30 30 50
Current A 0.15 0.15 0.25
Heating
Capacity kBtu/h 17.1 21.5 27.3
Capacity kW 5 6.3 8
Power input W 30 30 50
Current A 0.15 0.15 0.25
Heating capacity at
low temp.
kW / / /
Operating current A 0.15 0.15 0.25
Indoor motor
Brand Broad ocean Broad ocean Broad ocean
Model ZWK465B500011 ZWK465B500011 ZWK465A000007
Type DC DC DC
Insulation class E E E
IP class IP40 IP40 IP40
Power input W 30 30 50
Power output W 22 22 36
Capacitor μF / / /
Speed (High/
Middle/Low)
rpm 300-600 300-600 300-750
Indoor fan
Brand
Type Centrifugal Centrifugal Centrifugal
Quantity 1 1 1
Indoor coil
Number of rows 2 2 2
Tube pitch (a) x row
pitch (b)
mm 21*13.3 21*13.3 21*13.3
Fin spacing mm 1.45 1.45 1.45
Fin type (code) Hydrophilic aluminum
Tube outside dia.
and type
mm Φ7 Φ7 Φ7
Coil length x height
x width
mm 2132*147*26.6 2132*147*26.6 2132*168*26.6
Number of circuits 6 6 8
/ / /

Airwell AWSI-CFV007-N11 Specifications

General

Brand	Airwell
Model	AWSI-CFV007-N11
Category	Air Conditioner
Language	English
