EXPLODED VIEWS AND SPARE PARTS LISTS
SM FBFRPM 1-A.0 GB
14.16 Outdoor Unit: YDF047
No. Item Description Quantity
1 437045 UPPER COVER EL13 OU LARGE 1
2 417221 Side panel N OU10 1
3 436357 SMALL ELECTRICAL COVER OU 1
4 456714 FRONT PANEL OU10 1
5 439662 GRILLE OU10 2
6 439833 NEW BASE ASSY OU EXPORT 1
7 442712 COIL OU10-47 GR HDR 2R NEW R41 1
8 439650 AXIAL FAN D400*112 2
9 439651 MOTOR 70W,3S,OU10-50 2
10 417223 Side net panel N OU10 1
11 436358 OU LEADING HANDLE 1
12 439657 MOTOR SUPPORT OU10 1
12b 414226 Motor support flange OU-10 1
12c 414229 Motor support clamp bracket OU 1
13 190443 HEATER CRANKCASE MITSUBISHI CO 1
14 438824 COMPRESSOR ZP54KSE-TPM 1
15 441107 CAPILLARY ASSY OU10-47Z 1
16 438957 Tubing Assembly OU10-47 EXPORT 1
17 438886 BOARD TPHN 3G 12A (RoHS) 1
18 442017 CAPACITOR 3mF 450V P1/P2 2
19a 434716 THERMISTOR+CAP WTH CONNECTOR L 1
19b 402741 THERMISTOR WTH CONNECTOR L1250 1
21 445320 COMPRESSOR WIRING WITHOUT PLUG 1
22 402284 SUCTION ACCUMULATOR 5" x 3/4" 1
23 439661 AIR OUTLET RING OU10 2
24 437229 ELECTRICAL BOX TPHN 1
26 436352 RAISING HANDLE OU10 1
28 439656 SIDE COVER OU-8/10 1
33 442466 VALVE COIL L700 MOLEX-SANHUA 1
