ELECTRICAL DATA
SM FBFRPM 1-A.0 GB
7. ELECTRICAL DATA
7.1 Single Phase Units
MODEL FBF030 FBF036
Power Supply
To Outdoor To Outdoor
1PH – 230V – 50 Hz 1PH – 230V – 50 Hz
Max Current, A 19 23.4
Circuit Breaker 25 25
Power Supply Wiring No. X
Cross Section, mm
2
3 X 4 mm
2
3 X 4 mm
2
Interconnecting Cable RC
Model No. X Cross Section, mm
2
6 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor) 6 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
Interconnecting Cable ST
Model No. X Cross Section, mm
2
5 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor) 5 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
7.2 Three Phase Units
MODEL FBF030 FBF036
Power Supply
To Outdoor To Outdoor
3PH – 400V – 50 Hz 3PH – 400V – 50 Hz
Max Current, A 3 x 10.9 3 x 13.3
Circuit Breaker 3 x 16 3 x 16
Power Supply Wiring
No. X Cross Section, mm
2
5 X 1.5 mm
2
5 X 2.5 mm
2
Interconnecting Cable RC Model
No. X Cross Section, mm
2
6 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
6 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT
Sensor)
Interconnecting Cable ST
Model No. X Cross Section, mm
2
5 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
5 X 2.5 mm
2
+ 2 X 0.5 mm
2
(OCT
Sensor)
MODEL FBF045 FBF060
Power Supply
To Outdoor To Outdoor
3PH – 400V – 50 Hz 3PH – 400V – 50 Hz
Max Current, A 3 x 17.4 3 x 18.3
Circuit Breaker 3 x 16 3 x 25
Power Supply Wiring
No. X Cross Section, mm
2
5 X 2.5 mm
2
5 X 2.5 mm
2
Interconnecting Cable RC Model
No. X Cross Section, mm
2
6 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor) 6 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
Interconnecting Cable ST
Model No. X Cross Section, mm
2
5 X 2.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor) 5 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
(1) The power supply to the heating element kit is provided separately from the main power supply unit.
NOTE
Power wiring cord should comply with local lows and electrical regulations requirements.
