5-1
PERFORMANCE DATA & PRESSURE CURVES
SM FBFRPM 1-A.0 GB
5. PERFORMANCE DATA
5.1 FBF030 / GCN 30NRCT
5.1.1 Cooling Mode at 7.5m Tubing Connection.
230V : Indoor Fan at High Speed.
ENTERING AIR
DB OD COIL (°C)
DATA
ENTERING AIR WB/DB ID COIL ( °C)
15/21 17/24 19/27 21/29 23/32
15
(1)
TC 8.80 9.12 9.33 9.55 9.70
SC 5.96 6.22 6.46 6.62 6.75
PI 2.07 2.07 2.08 2.08 2.09
20
(1)
TC 8.52 8.97 9.26 9.48 9.68
SC 5.85 6.16 6.42 6.61 6.73
PI 2.25 2.26 2.26 2.28 2.28
25
TC 8.06 8.70 9.15 9.42 9.65
SC 5.70 6.04 6.37 6.56 6.68
PI 2.43 2.45 2.46 2.48 2.50
30
TC 7.53 8.20 8.86 9.18 9.45
SC 5.52 5.86 6.23 6.42 6.54
PI 2.62 2.66
2.68
2.70 2.73
35
TC 6.98 7.57
8.35
8.77 9.18
SC 5.25 5.62 6.09 6.27 6.39
PI 2.83 2.87
2.92
2.94 2.96
40
TC 6.34 6.91
7.54
8.24 8.66
SC 4.94 5.32 5.76 5.94 6.07
PI 3.05 3.10 3.15 3.19 3.22
46
TC 5.50 6.02 6.62 7.31 7.88
SC 4.55 4.88 5.25 5.44 5.56
PI 3.33 3.38 3.46 3.51 3.55
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OD – Outdoor
(1) Marked area is below standard operating limits. For operating in low ambient
conditions, refer to Optional Accessories (Chapter 15).
