5-5
PERFORMANCE DATA & PRESSURE CURVES
SM FBFRPM 1-A.0 GB
5.4 FBF030 / YDF030
5.4.1 Cooling Mode at 7.5m Tubing Connection.
230V : Indoor Fan at High Speed.
ENTERING AIR
DB OD COIL (°C)
DATA
ENTERING AIR WB/DB ID COIL ( °C)
15/21 17/24 19/27 21/29 23/32
15
(1)
TC 8.80 9.12 9.33 9.55 9.70
SC 6.05 6.31 6.56 6.72 6.84
PI 2.04 2.05 2.05 2.05 2.07
20
(1)
TC 8.52 8.97 9.26 9.48 9.68
SC 5.93 6.25 6.52 6.70 6.83
PI 2.22 2.22 2.23 2.24 2.25
25
TC 8.06 8.70 9.15 9.42 9.65
SC 5.78 6.13 6.47 6.65 6.78
PI 2.40 2.41 2.43 2.44 2.46
30
TC 7.53 8.20 8.86 9.18 9.45
SC 5.60 5.95 6.33 6.51 6.63
PI 2.58 2.62
2.64
2.67 2.69
35
TC 6.98 7.57
8.35
8.77 9.18
SC 5.32 5.71 6.18 6.36 6.48
PI 2.79 2.83
2.88
2.90 2.92
40
TC 6.34 6.91
7.54
8.24 8.66
SC 5.02 5.40 5.85 6.03 6.16
PI 3.01 3.05 3.10 3.14 3.17
46
TC 5.50 6.02 6.62 7.31 7.88
SC 4.62 4.95 5.33 5.52 5.64
PI 3.28 3.33 3.41 3.46 3.50
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OD – Outdoor
(1) Marked area is below standard operating limits. For operating in low ambient
conditions, refer to Optional Accessories (Chapter 15).
