PERFORMANCE DATA & PRESSURE CURVES
SM FBFRPM 1-A.0 GB
5.7 FBF036 / GCN 37NRC
5.7.1 Cooling Mode at 7.5m Tubing Connection.
230V : Indoor Fan at High Speed.
ENTERING AIR
DB OD COIL (°C)
DATA
ENTERING AIR WB/DB ID COIL ( °C)
15/21 17/24 19/27 21/29 23/32
15
(1)
TC 10.01 10.37 10.62 10.87 11.03
SC 6.65 6.93 7.20 7.38 7.52
PI 2.47 2.48 2.48 2.49 2.50
20
(1)
TC 9.69 10.21 10.53 10.78 11.01
SC 6.52 6.87 7.16 7.36 7.50
PI 2.69 2.70 2.70 2.72 2.72
25
TC 9.17 9.90 10.41 10.72 10.98
SC 6.35 6.74 7.11 7.31 7.45
PI 2.90 2.92 2.94 2.96 2.98
30
TC 8.57 9.33 10.08 10.44 10.75
SC 6.15 6.54 6.95 7.15 7.29
PI 3.13 3.18
3.20
3.23 3.26
35
TC 7.94 8.61
9.50
9.98 10.45
SC 5.85 6.27 6.79 6.99 7.12
PI 3.38 3.43
3.49
3.52 3.54
40
TC 7.22 7.86
8.57
9.37 9.86
SC 5.51 5.93 6.42 6.63 6.76
PI 3.64 3.70 3.76 3.81 3.85
46
TC 6.26 6.85 7.53 8.32 8.96
SC 5.08 5.44 5.86 6.06 6.20
PI 3.98 4.04 4.13 4.19 4.24
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OD – Outdoor
(1) Marked area is below standard operating limits. For operating in low ambient
conditions, refer to Optional Accessories (Chapter 15).
