5-13
PERFORMANCE DATA & PRESSURE CURVES
SM FBFRPM 1-A.0 GB
5.10 FBF036 / GCN 37NRCT
5.10.1 Cooling Mode at 7.5m Tubing Connection.
230V : Indoor Fan at High Speed.
ENTERING AIR
DB OD COIL (°C)
DATA
ENTERING AIR WB/DB ID COIL ( °C)
15/21 17/24 19/27 21/29 23/32
15
(1)
TC 10.33 10.70 10.95 11.21 11.38
SC 6.76 7.05 7.32 7.50 7.64
PI 2.35 2.36 2.36 2.37 2.38
20
(1)
TC 9.99 10.53 10.87 11.12 11.36
SC 6.62 6.98 7.28 7.48 7.62
PI 2.56 2.56 2.57 2.59 2.59
25
TC 9.46 10.21 10.73 11.06 11.33
SC 6.45 6.85 7.22 7.43 7.57
PI 2.76 2.78 2.80 2.82 2.84
30
TC 8.84 9.63 10.40 10.77 11.09
SC 6.25 6.64 7.06 7.27 7.41
PI 2.98 3.02
3.05
3.07 3.10
35
TC 8.19 8.88
9.80
10.29 10.78
SC 5.94 6.37 6.90 7.10 7.24
PI 3.21 3.27
3.32
3.35 3.36
40
TC 7.44 8.10
8.84
9.67 10.17
SC 5.60 6.03 6.53 6.73 6.87
PI 3.47 3.52 3.58 3.62 3.66
46
TC 6.46 7.06 7.77 8.58 9.25
SC 5.16 5.53 5.95 6.16 6.30
PI 3.79 3.84 3.93 3.99 4.03
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OD – Outdoor
(1) Marked area is below standard operating limits. For operating in low ambient
conditions, refer to Optional Accessories (Chapter 15).
