5-17
PERFORMANCE DATA & PRESSURE CURVES
SM FBFRPM 1-A.0 GB
5.13 FBF045 / YDF047
5.13.1 Cooling Mode at 7.5m Tubing Connection.
230V : Indoor Fan at High Speed.
ENTERING AIR
DB OD COIL (°C)
DATA
ENTERING AIR WB/DB ID COIL ( °C)
15/21 17/24 19/27 21/29 23/32
15
(1)
TC 13.49 13.97 14.30 14.64 14.86
SC 9.13 9.52 9.89 10.14 10.32
PI 3.23 3.24 3.25 3.25 3.27
20
(1)
TC 13.05 13.76 14.19 14.53 14.84
SC 8.95 9.43 9.83 10.11 10.29
PI 3.51 3.52 3.53 3.55 3.56
25
TC 12.35 13.33 14.02 14.44 14.80
SC 8.72 9.25 9.75 10.03 10.22
PI 3.79 3.82 3.85 3.87 3.90
30
TC 11.55 12.58 13.59 14.07 14.49
SC 8.44 8.97 9.54 9.82 10.01
PI 4.09 4.15
4.19
4.22 4.26
35
TC 10.69 11.60
12.80
13.44 14.08
SC 8.03 8.61 9.32 9.59 9.78
PI 4.41 4.49
4.56
4.59 4.62
40
TC 9.72 10.59
11.55
12.63 13.28
SC 7.57 8.14 8.82 9.10 9.28
PI 4.76 4.83 4.92 4.98 5.03
46
TC 8.44 9.22 10.14 11.21 12.08
SC 6.97 7.47 8.04 8.32 8.51
PI 5.20 5.28 5.40 5.48 5.54
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OD – Outdoor
(1) Marked area is below standard operating limits. For operating in low ambient
conditions, refer to Optional Accessories (Chapter 15).
