5-21
PERFORMANCE DATA & PRESSURE CURVES
SM FBFRPM 1-A.0 GB
5.16 FBF060 / YCF055
5.16.1 Cooling Mode at 7.5m Tubing Connection.
230V : Indoor Fan at High Speed.
ENTERING AIR
DB OD COIL (°C)
DATA
ENTERING AIR WB/DB ID COIL ( °C)
15/21 17/24 19/27 21/29 23/32
15
(1)
TC 14.97 15.50 15.87 16.24 16.49
SC 10.15 10.58 10.99 11.27 11.47
PI 3.56 3.57 3.57 3.58 3.60
20
(1)
TC 14.48 15.26 15.74 16.12 16.46
SC 9.94 10.48 10.93 11.24 11.44
PI 3.86 3.88 3.89 3.91 3.92
25
TC 13.70 14.79 15.55 16.02 16.41
SC 9.69 10.28 10.84 11.15 11.36
PI 4.18 4.20 4.23 4.26 4.29
30
TC 12.81 13.95 15.07 15.61 16.07
SC 9.38 9.97 10.60 10.92 11.12
PI 4.50 4.57
4.61
4.65 4.69
35
TC 11.86 12.87
14.20
14.91 15.62
SC 8.92 9.57 10.36 10.66 10.87
PI 4.86 4.94
5.02
5.06 5.09
40
TC 10.79 11.74
12.81
14.01 14.73
SC 8.41 9.05 9.80 10.11 10.32
PI 5.24 5.32 5.41 5.48 5.53
46
TC 9.36 10.23 11.25 12.43 13.40
SC 7.75 8.30 8.94 9.25 9.45
PI 5.73 5.81 5.94 6.03 6.10
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OD – Outdoor
(1) Marked area is below standard operating limits. For operating in low ambient
conditions, refer to Optional Accessories (Chapter 15).
