CONTROL SYSTEM
SM FBFRPM 1-A.0 GB
11.2 Control Function
11.2.1 Abbreviations
AC - Alternate Current
A/C - Air-Conditioner
ANY - ON or OFF status
CLOCK - ON/OFF Opera tion Input, (dry conta ct)
COMP - Compressor
CPU - Central Processing Unit
CTV - Compensation Temperature Value
HE - Heating Element
HPC - High Pressure Control
H/W - Hardware
ICP - Indoor Condensation Pump
ICT - Indoor Coil Temperature (RT2) sensor
IF, IFAN - Indoor Fan
IR - Infrared
LEVEL1 - Normal Water Level
LEVEL2/3 - Medium/High Waterlevel
LEVEL4 - Overflow Level
Max - Maximum
Min - Minimum
min - Minute (time)
NA - Not Applicable
OCP - Outdoor Condensation Pump
OCT - Outdoor Coil Temperature (RT3) sensor
OF, OFAN - Outdoor Fan
OPER - Operate
Para. - Paragraph
RAT - Return Air Temperature (RT1) sensor
RC - Reverse Cycle (Heat Pump)
R/C - Remote Control
RCT - Remote Control Temperature
RH - Resistance Hea ter
RT - Room Temperature (i.e. RCT in IFEEL mode, RAT other
wise)
RV - Reversing Valve
SB, STBY - Stand-By
sec - Second (time)
Sect - Section
SH - Supplementary Heater
SPT - Set Point Temperature
ST - Standard (Model with Cooling Only)
S/W - Software
TEMP - Temperature
W/O - Without
'T - The difference between SPT and RT.
in Heat Mode: 'T = SPT - RT
in Cool/Dr
