EXPLODED VIEWS AND SPARE PARTS LISTS
SM FBFRPM 1-A.0 GB
14.2 Indoor Unit: FBF030
No. Item Description Quantity
1 201144490004 Filter 3
2 201244290001 Grille clamp 2
3 201144490006 Grille 1
4 201144290012 Grille clamp 2
5 201244490004 Grille strengthening rib 1
6 201144290033 Volute shell 3
7 201144290007 Grille lock 2
8 201144290015 Plastic fan 3
9 201280200006 Motor clamp 1
10 201280200005 Motor clamp 1
11 201144290032 Volute shell 3
12 201280200007 Board 1
13 201244490001 Middle beam 1
14 201244490017 E-part box cover board 1
15 203344490025 E-part box ass'y 1
15.1 467300253R NFC fixed rpm controller 1
15.2 202401100017 Capacitor 1
15.3 202301450121 Wire joint 1
15.4 202301400207 Wire joint, 6p 1
15.5 4523162 Transformer 1
15.6 467580012R Step Motors Adapter 1
16 201144290009 Left cover 1
17 201244290014 Installation board 1
18 201244490006 Base ass'y 1
19 201144490001 Rear cover 1
20 201544390005 Evaporator ass'y 1
20.1 467400039 Indoor Coil Temperature Sensor 1
21 201244290013 Installation board 1
22 202244490003 Foam ass'y 1
23 202244290004 Foam ass'y 1
24 201244290017 Evaporator Left support 1
25 202244290005 Foam ass'y 1
26 201244290018 Support board 1
27 201244290003 Evaporator right clapboard 1
28 201244290004 Evaporator left clapboard 1
29 201144290008 Right cover 1
30 201144290016 Display panel box 1
31 467300227R Display assy with cable 1
32 201144290017 Manual button 1
33 201144390001 Air outlet frame ass'y 1
34 202244290002 Foam 1
35 201244290023 Drainage pan holder 2
36 202244490006 Drainage pan ass'y 1
36.1 201144290018 Plastic cover 1
37 202400400390 Motor 1
38 201144390002 Panel ass'y-Airwell 1
201144390006 Panel ass'y-Electra 1
39 467200010R Remote Controller 1
40 467400025 Indoor Air Inlet Temperature Sensor 1
41 4520416 Defrost cable 1
