Airwell FBF030 - Page 94

14-6
EXPLODED VIEWS AND SPARE PARTS LISTS
SM FBFRPM 1-A.0 GB
14.6 Indoor Unit: FBF060
No. Item Description Quantity
1 201144690004 Grille ass'y 2
2 201280200006 Motor clamp 2
3 201280200005 Motor clamp 2
4 201244690003 Filter bracket 2
5 201244290013 Installation board 1
6 201244290014 Installation board 1
7 201244690004 Filter bracket 2
8 201144690003 Sealed board 1
9 201144690002 Sealed board 1
10 201244690002 Pipe clamp board 1
11 201144690006 Right cover 1
12 201144690005 Left cover 1
14 201144690053 Display installation box 1
15 201144690054 Air outlet frame ass'y 1
15.1 467300227R Display assy with cable 1
16 201244690006 Base ass'y 1
17 201144690011 Plastic fan 4
18 201144690033 Volute shell 4
19 202400400391 Motor 2
20 201244290021 Motor bracket 2
21 201144690032 Volute shell 4
22 201244690009 Middle beam 1
23 201244490017 E-part box cover board 1
24 203344690006 E-part box ass'y 1
24.1 467300253R NFC fixed rpm controller 1
24.2 202401000005 Capacitor 2
24.3 202301450121 Wire joint 1
24.4 202301400207 Wire joint, 6p 1
24.5 4523162 Transformer 1
24.6 467580012R Step Motors Adapter 1
26 201244690016 Drainage pan ass'y 1
27 201244790001 Top cover ass'y-Airwell 1
201244790003 Top cover ass'y-Electra 1
28 201144290018 Plastic cover 1
29 202244690000 Foam 2
30 201144690007 Filter 4
31 201544790075 Evaporator ass'y 1
31.1 467400039 Indoor Coil Temperature Sensor 1
32 467200010R Remote Controller 1
33 467400025 Indoor Air Inlet Temperature Sensor 1
34 4520416 Defrost cable 1
