14-8
EXPLODED VIEWS AND SPARE PARTS LISTS
SM FBFRPM 1-A.0 GB
14.8 Outdoor Unit: YDF030
No. Item Description Quantity
1 437045 UPPER COVER EL13 OU LARGE 1
2 402930 SIDE PANEL OU8-33 1
3 436357 SMALL ELECTRICAL COVER OU 1
4 402928 FRONT PANEL/COLLECTOR OU8-33 E 1
5 437091 OU SQUARE FAN GUARD 1
6 433722 BASE ASSY OU7-24C EXPORT R410A 1
7 442709 COIL OU8-30 R410 NEW EXPORT 1
8 4529604 AXIAL FAN D493*143 1
9 434211 MOTOR 70W,2S,OU7/8 1
10 403996 SIDE GUARD OU8-33Z 1
11 436358 OU LEADING HANDLE 1
12 439775 MOTOR SUPPORT OU8 1
14 438829 COMPRESSOR GPT330PAB 1
15 433822 CAPILLARY ASSY OU8-30 R410A RC 1
16 442706 TUBING ASSY OU8-30 NEW EXPORT 1
17 413496 BOARD TPHN 5F (RoHS) 1
18 442007 CAPACITOR 6mf 450V P1/P2 1
19a 434716 THERMISTOR+CAP WTH CONNECTOR L 1
20 442010 CAPACITOR 60mF 400V P1/P2 1
21 438850 COMPRESSOR WIRING TPHN-5F OU10 1
22 440002 SUCTION ACCUMULATOR 5" x 5/8" 1
24 437229 ELECTRICAL BOX TPHN 1
28 439656 SIDE COVER OU-8/10 1
33 442466 VALVE COIL L700 MOLEX-SANHUA 1
39 BIG SOFT STARTER (RoHS) 1
41 442022 CAPACITOR SOFT STARTER 161-193 1
44 192207 CONTACTOR 230V, 40A 1
