14-10
EXPLODED VIEWS AND SPARE PARTS LISTS
SM FBFRPM 1-A.0 GB
14.10 Outdoor Unit: GCN 30NRCT
No. Item Description Quantity
1 437045 UPPER COVER EL13 OU LARGE 1
2 402930 SIDE PANEL OU8-33 1
3 436357 SMALL ELECTRICAL COVER OU 1
4 402928 FRONT PANEL/COLLECTOR OU8-33 E 1
5 437091 OU SQUARE FAN GUARD 1
6 433294 NEW BASE ASSY OU 2005 EXPORT R 1
7 433807 COIL OU8-30 GR HDR R410A 1
8 4529604 AXIAL FAN D493*143 1
9 434211 MOTOR 70W,2S,OU7/8 1
10 403996 SIDE GUARD OU8-33Z 1
11 436358 OU LEADING HANDLE 1
12 439775 MOTOR SUPPORT OU8 1
13 190443 HEATER CRANKCASE MITSUBISHI CO 1
14 433298 COMPRESSOR NN33YCAMT 1
15 433822 CAPILLARY ASSY OU8-30 R410A RC 1
16 433974 TUBING ASSY OU8-30 R410A 1
17 438888 BOARD TPHN 3E 9A (RoHS) 1
18 442007 CAPACITOR 6mf 450V P1/P2 1
19a 434716 THERMISTOR+CAP WTH CONNECTOR L 1
21 437280 COMPRESSOR WIRING OU10-3PH MIT 1
22 402284 SUCTION ACCUMULATOR 5" x 3/4" 1
24 437229 ELECTRICAL BOX TPHN 1
28 439656 SIDE COVER OU-8/10 1
33 442466 VALVE COIL L700 MOLEX-SANHUA 1
