PERFORMANCE DATA & PRESSURE CURVES
Revision 0
5.19 FLO 30N 1PH R410A
5.19.1 Cooling Mode at 7.5m Tubing Connection.
230V : Indoor Fan at High Speed.
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OU – Outdoor
(1) Marked area is below standard operating limits. For operating in low ambient
conditions, refer to Optional Accessories (Chapter 14).
ENTERING AIR
DB OU COIL (°C)
DATA ENTERING AIR WB/DB ID COIL ( °C)
15/21 17/24 19/27 21/29 23/32
TC
9.13 9.45 9.68 9.91 10.06
SC
5.88 6.13 6.37 6.53 6.65
15
(1)
PI
2.18 2.19 2.19 2.20 2.21
TC
8.83 9.31 9.60 9.83 10.00
SC
5.76 6.07 6.33 6.51 6.6320
(1)
PI
2.37 2.38 2.39 2.40 2.40
TC
8.36 9.02 9.49 9.77 10.01
SC
5.61 5.95 6.28 6.46 6.58
25
PI
2.56 2.58 2.60 2.61 2.63
TC
7.81 8.51 9.19 9.52 9.80
SC
5.43 5.78 6.14 6.32 6.44
30
PI
2.76 2.80 2.83 2.85 2.88
TC
7.23 7.85 8.66 9.09 9.52
SC
5.17 5.54 6.00 6.17 6.29
35
PI
2.98 3.03 3.08 3.10 3.12
TC
6.58 7.16 7.81 8.54 8.98
SC
4.87 5.24 5.68 5.86 5.98
40
PI
3.22 3.26 3.32 3.36 3.39
TC
5.71 6.24 6.86 7.58 8.17
SC
4.49 4.81 5.18 5.36 5.48
46
PI
3.51 3.57 3.65 3.70 3.74
