12.A CONTROL SYSTEM FLO 30 N
12A.1. Electronic Control
12A.1.1. Introduction
The electronic control information is designed for service applications, and is common
to the following groups of air-conditioners:
• ST/ RC group - Cooling only / cooling and heating by heat pump.
• SH group - Cooling and heating by heat pump and supplementary
heater.
• RH group - Cooling, heating by heaters only.
12Α.1.2. Jumpers Settings
GROUP J6 Setting J2 Setting
ST / RC Open Open
SH Closed Open
RH Closed Closed
