12A.6. Heating Mode
112Α.6.1. Heating Mode - General
• Compensation Procedure:
The compensation procedure comes to solve the problem of the temperature
distribution by height during heat mode according to this procedure.
• When I feel is OFF during heat mode: RT= RAT – CTV.
When I feel is ON during heat mode: RT= RCT.
• CTV is a compensation temperature value to be used from the following table (CTV
table).
• RCV is a reference compensation value (relation between cells).
• IOC is a compensation value when IFAN is OFF.
• The values of RCV and IOC to be set in the following table are taken from the RCV
and IOC table below depending on the model.
CTV table:
I IFAN
ICT
OFF LOW MEDIUM HIGH
40 > ICT IIOC RRCV+0 RRCV+0 RRCV+0
50 > ICT ≥ 40 IIOC RRCV+0 RRCV+0 RRCV+0
ICT ≥ 50 IIOC+1 RRCV+1 RRCV+1 RRCV+1
RCV and IOC table
• The following table includes the RCV and IOC default values. These values are
set as values in the above compensation table.
Model RCV IOC
FLO 30 N +2
o
C+2
o
C
WNG-28 +2
o
C+2
o
C
WNG-25 +2
o
C+2
o
C
No compensation will be activated in Forced operation modes.
