12a-33
CONTROL SYSTEM
Revision 0
12Α.17.2. By Remote Control Settings:
a. 1: TURNING ON THE POWER.
Turn ON the power, make sure that the unit is in operation.
b. STEP 2 : ENABLE SELF-TEST MODE
• Use the remote control to send the first settings to display / indoor unit
HEAT mode, HIGH IFAN, set temperature to 16 ºC, no I-FEEL Sleep or
any other timer settings are needed.
• Cover the IR transmitter components in the remote control so that it will
not transmit the signals to the indoor unit display.
• Use the remote control to send the second settings to display / indoor unit
COOL mode, LOW IFAN, no I-FEEL Sleep or any other timer settings.
• Uncover the remote control IR transmitter and change the temperature
settings. If the display/indoor unit receive the settings properly the
following steps will start:
c. STEP 3: MODEL SETTING CONFIRMATION
• The STAND-BY and COOL LEDS will indicate the operation mode as
follows:
COOL LED STAND-BY LED OPERATION MODE
OFF ON ST
OFF OFF RC
ON OFF SH
ON ON RH
• Testi the Model configuration. Selected by the COMP, STAND-BY, TIMER
LEDS and FILTER will indicate the model configuration as follows (the
relevant line for this manual is highlighted):
FILTER LED TIMER LED OPERATE LED COMP MODEL
OFF OFF OFF ON FLO
ON OFF ON ON WMN1
OFF ON OFF OFF WMN 4
ON OFF ON OFF WMN 2/WHX
ON ON ON OFF WMN 3
In this term the step motor will turn to HOME POSITION.
