2-11
PRODUCT DATA SHEET
Revision 0
Model Indoor Unit FLO 30N
Model Outdoor Unit GC30NT(OU830T)
Installation Method of Pipe Flared
Characteristics Units Cooling Only Cooling Heating
Capacity
(1)
Btu/hr 29580 29580 31630
kW 8.67 8.67 9.27
Power input
(1)
kW 3.09 3.09 3.25
EER (Cooling) or COP(Heating)
(1)
W/W 2.81 2.81 2.85
Energy efficiency class C C C
Power supply V/Ph/Hz 400V/3PH/50Hz
Rated current A 10.2 10.2 10.6
Starting current A 35
Circuit breaker rating A 16
INDOOR
Fan type & quantity Cross flow x 1
Fan speeds H/M/L RPM 1300/1200/1000
Air flow
(2)
H/M/L m3/hr 1250/1040/830
External static pressure Min-Max Pa N/A
Sound power level
(3)
H/M/L dB(A) 64/59/53
Sound pressure level
(4)
H/M/L dB(A) 54/52/41
Moisture removal l/hr 3.6
Condensate drain tube I.D mm 16
Dimensions WxHxD mm 1200X340X236
Weight kg 18.5
Package dimensions WxHxD mm 1305X430X325
Packaged weight kg 25.5
Units per pallet units 12
Stacking height units 6 levels
OUTDOOR
Refrigerant control Capillary
Compressor type, model SCROLL AQ036YAA
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 850
Air flow H/L m3/hr 3110
Sound power level H/L dB(A) 69
Sound pressure level
(4)
H/L dB(A) 62
Dimensions WxHxD mm 900X860X340
Weight kg 78
Package dimensions WxHxD mm 903X907X435
Packaged weight kg 82
Units per pallet Units 6
Stacking height units 3 levels
Refrigerant type R410A
Refrigerant charge less distance kg/m 2.13kg / 7.5m
Additional charge gr/m 30
Connections between
units
Liquid line In.(mm) 3/8”(9.53)
Suction line In.(mm) 3/4”(15.88)
Max.tubing length m. 30
Max.height
difference
m. 10
Operation control type Remote control
(1)
Rating conditions in accordance with ISO 5151, ISO 13253 (for ducted units) and EN 14511.
(2)
Airflow in ducted units; at nominal external static pressure.
(3)
Sound power in ducted units is measured at air discharge.
(4)
Sound pressure level measured at 1 meter distance from unit.
