12a-3
CONTROL SYSTEM
Revision 0
12A.3. Main PCB Controller
12Α.3.1. Display Board
Display (LEXAN) Display PCB Ass’y
OPR’ (STBY RED; ON: GREEN)
TIMER
FILTER LED
LCD SCREEN
FRESH, ION / ESF
RECIVER
OPR’ (STBY RED; ON: GREEN)
FRESH, ION / ESF
LCD SCREEN
RECIVER
TIMER
FILTER LED
FLO24/30
