12a-15
CONTROL
SYSTEM
Revision
0
12Α.6.4.
OF
AN Operation for RC and SH
•
As a general rule for
RC and SH groups
, excluding protection modes,
OF
AN starts with the compressor
.
•
When OF
AN is then ON it will operate according to the following conditions:
a) OF
AN operates together with the compressor
.
b) When
(RT ≥ SPT
– 2) and ICT ≥ 50
the 4.7k Ohm resistor is not
connected to the OCT
, OF
AN will operate according to the following curve:
0
3
ON
OFF
OCT
OFA
N
88
90
