PRODUCT DATA SHEET
SM PNXADCI 1-A.1 GB
2.4 PNXA 21 DCI
Model Indoor Unit PNXA 21 DCI
YBD 022tinUroodtuOledoM
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Capacity
(1)
Btu/hr 20470(6140-23200)
21500(5460-
26950)
kW 6.00(1.80-6.80) 6.30(1.60-7.90)
Power input
(1)
kW 1.82(0.50-2.40) 1.74(0.50-2.40)
EER (Cooling) or COP(Heating)
(1)
W/W 3.30 3.62
(QHUJ\HI¿FLHQF\FODVV AA
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 8.2 7.8
Starting current A 15
Circuit breaker rating A 20
INDOOR
Fan type & quantity &URVVÀRZ[
Fan speeds H/M/L RPM 1250/1100/1000
$LUÀRZ
(2)
H/M/L m3/hr 900/760/620
([WHUQDOVWDWLFSUHVVXUH 0LQ0D[ Pa 0
Sound power level
(3)
H/M/L dB(A) 56/53/48
Sound pressure level
(4)
H/M/L dB(A) 45/40/34
Moisture removal l/hr 2.4
61mmD.IebutniardetatsnednoC
012[592[0601mmD[H[WsnoisnemiD
51gkthgieW
Package dimensions :[+[Dmm 1[[
81gkthgiewdegakcaP
tellaprepst
inu61stinutellaprepstinU
slevel8stinuthgiehgnikcatS
OUTDOOR
Refrigerant control EEV
Compressor type,model Two Rotary,GMCC DA150S1C-20FZ
Fan type & quantity 3URSHOOHUGLUHFW[
Fan speeds H/L RPM 800
$LUÀRZ H/L m3/hr 2860
Sound power level H/L dB(A) 66
Sound pressure level
(4)
H/L dB(A) 56
Dimensions :[+[' mm [[
Weight kg 45
Package dimensions :[+[' mm [[
Packaged weight kg 49
Units per pallet Units 9 units per pallet
Stacking height units 3 levels
Refrigerant type R410A
Refrigerant chargless distance kg/m 1.60/7.5
Additional charge per 1 meter g/m No need
Connections between units
Liquid line In.(mm) 1/4”(6.35)
Suction line In.(mm) 1/2”(12.7)
0D[WXELQJOHQJWhm. 0D[
0D[KHLJKW
difference
m. 0D[
Operation control type Remote control
Heating elements kW
Others
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2) $LUÀRZLQGXFWHGXQLWVDWQRPLQDOH[WHUQDOVWDWLFSUHVVXUH
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
