Aiwa CSD-EL33 Service Manual

2
SPECIFICATIONS
<Tuner section>
(FM)
Tuning range 87.5 MHz to 108.0 MHz
Antenna Rod antenna
(AM)
Tuning range 530 kHz to 1710 kHz (10 kHz step)
531 kHz to 1602 kHz (9 kHz step)
Antenna Ferrite bar antenna
<Cassette deck section>
Track format 4 track, 2 channels stereo
Frequency response Normal tape: 50 Hz - 12500 Hz
Recording system AC bias
Erasing system Magnet erase
Heads Recording/Playback head x 1
Erasure head x 1
<Compact disc player section>
Laser Semiconductor (λ = 780 nm)
D-A converter 1 bit dual
<General>
Speakers 100 mm cone type (2)
Power output 2.5 W + 2.5 W (10% T.H.D./7Ω DC)
2 W + 2 W (DIN 1% Rated Power)
Output Headphones (stereo minijack)
Power requirements DC 12 V using eight size C (R14)
batteries
<U Model>
120 V AC, 60 Hz
<HA Model>
110 - 120 V/ 220 - 240 V AC
Switchable, 50/60 Hz
Power consumption 18 W
Dimensions of main unit (W x H x D)
445 x 168 x 237 mm
(17
5
/
8
x 6
5
/
8
x 9
3
/
8
in.)
Weight of main unit 4.1 kg (9 lb 1 oz.)
not including batteries
• Design and specifications are subject to change without notice.
REF. NO PART NO. KANRI DESCRIPTION
NO.
ACCESSORIES LIST
1 8Z-CH2-906-010 IB,LH(ESP)FM<HA>
1 8Z-CH2-905-010 IB,U(ESF)FM<U>
2 8Z-CK4-962-010 RC UNIT,RC-ZAT04 (VS)
! 3 87-A80-119-010 AC CORD SET ASSY,AZ<HA>
! 3 87-A80-027-010 AC CORD SET,U BLK SPT2<U>
